| Camera |
|
| Image Sensor |
1/4" Progressive Scan CMOS |
| Min. Illumination |
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Lens |
2.8mm, horizontal field of view 92° |
| Lens Mount |
M12 |
| Day &Night |
IR cut filter with auto switch |
| DNR |
3D DNR |
| Wide Dynamic Range |
Digital WDR |
| Pan/Tilt |
Pan: 0° to 355°; Tilt: -10°to 90° |
| Compression Standard |
|
| Video Compression |
Main stream: H.264
Sub stream: H.264/MJPEG |
| H.264 Type |
Baseline Profile/Main Profile |
| Video Bit Rate |
32 Kbps – 8 Mbps |
| Audio Bit Rate |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Compression |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-64Kbps(MP2L2)/PCM |
| Image |
|
| Max. Resolution |
1280 × 720 |
Main Stream
Max. Frame Rate |
50Hz: 25 fps (1280 × 720)
60Hz: 30 fps (1280 × 720) |
Sub Stream
Max. Frame Rate |
50Hz: 25 fps (704 × 576, 352 × 288, 640 × 480, 320 × 240)
60Hz: 30 fps (704 × 480, 352 × 240, 640 × 480, 320 × 240) |
| Image Settings |
Support rotate mode, brightness, saturation, sharpness, contrast are adjustable via client software |
| Day/Night Switch |
Support auto/scheduled |
| Backlight Compensation |
Support, zone optional |
| Region of Interest |
Support 1 fixed region for each stream |
| Audio |
|
| Environment Noise Filter |
Support |
| Audio Input/Output |
Support mono soundtrack |
| Audio Sampling Rate |
Max. 16 kHz |
| Network |
|
| Network Storage |
Support Micro SD/SDHC/SDXC card, up to 128 GB local storage |
| Detection |
Motion Detection, Dynamic Analysis |
| Alarm Trigger |
Video Tampering Alarm, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, IGMP, QoS, IPv6 |
| Standard |
ISAPI |
| General Function |
One-key reset, Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark |
| Interface |
|
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| On-board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Audio Interface |
1 build-in microphone, 1 build-in speaker |
| Reset |
Yes |
| Wi-Fi |
Wireless Standards
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz - 2.4835 GHz |
| Channel Bandwidth |
20/40MHz Support |
| Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates |
11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps |
| Wireless Range |
50 meters (The performance varies based on actual environment) |
| General |
|
| Operating Conditions |
-10°C – 40°C (14°F – 104°F), Humidity 95% or less (non-condensing) |
| Power Supply |
Camera: DC 5V ± 10%, micro USB interface |
| Current |
Max. 1.4A (estimated) |
| Power Consumption |
Max. 7W |
| IR Range |
Approx. 5 meters |
| Material |
Plastic |
| Memory Card |
DS-2CV2Q01FD-IW: no memory card included
DS-2CV2Q01FD-IW/16 GB-T : includes a 16 GB memory card
DS-2CV2Q01FD-IW/32 GB-T : includes a 32 GB memory card
DS-2CV2Q01FD-IW/64 GB-T : includes a 64 GB memory card |
| Dimensions |
Φ82.4 × 113.6 mm (Φ3.25''× 4.47'') |
| Weight (include package) |
434g (0.96 lbs) |
