Camera |
|
Image Sensor |
1/2.8" Progressive Scan CMOS |
Min. Illumination |
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Speed |
1/3 s to 1/100,000 s |
Lens |
f=2.8 ?? |
Day &Night |
IR cut filter |
Wide Dynamic Range |
DWDR |
DNR |
3D DNR |
Viewing Angle |
105° |
Pan/Tilt |
Pan: 0° to 355°; Tilt: -10°to 90° |
Compression Standard |
|
Video Compression |
H.264/MJPEG |
Video Bit Rate |
32 Kbps – 8 Mbps |
Audio Compression |
G.711 / G.722.1 / G.726 / MP2L2 / PCM |
Audio Bit Rate |
64Kbps (G.711) / 16Kbps (G.722.1) / 16Kbps (G.726) / 32-128Kbps (MP2L2) |
Image |
|
Max. Resolution |
1920x1080 |
Main Stream |
1920x1080, 1280?960, 1280?720 - 25 fps |
Sub Stream |
704?576, 352?288 - 25 fps |
Video Options |
Saturation / Brightness / Contrast - Configurable using client software or a web browser |
Other |
Mirror reflection, DWDR, BLC, ROI |
Network |
|
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, IGMP, QoS, IPv6 |
Standard |
ISAPI |
Detection |
Motion detector, dynamic analysis of the frame |
Intelligent alarm |
Motion Detection, Video Tampering, Video Loss, Network Disconnect, IP address conflict, Storage exception |
Interface |
|
Audio Interface |
Built-in microphone and speaker |
Network Interface |
1-RJ45 10M / 100M and 1-RS-485 interface |
Storage |
Support for Micro SD (SD / SDHC / SDXC) up to 128GB |
Reset |
Yes |
Wi-Fi |
|
Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz - 2.4835 GHz |
Channel Bandwidth |
20/40MHz Support |
Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
General |
|
Power Supply |
5 VDC±10% / 1.4? |
Power Consumption |
Max. 7W |
IR Range |
Up to 10 meters |
Working Temperature |
-10°C ~ 60°C |
Dimensions |
82.4x113.6 mm |
Weight |
434 g |
Material |
Plastic |
