| Server |
| Image compression |
: |
JPEG (Motion JPEG), MPEG-4 |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 192 x 144 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion), MPEG-4 |
| Frame rate |
: |
*1 Max. 30 frames/sec (640 x 480*4, 320 x 240 or 192 x 144) |
| Security |
: |
User ID/Password, HTTPS |
| Supported protocols |
: |
IPv4 / IPv6 Dual-Stack. IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnPTM, SMTP Authentication, RTP, RTSP*5, RTCP, SSL, HTTPS, TLS. IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP*5, RTCP, SSL, HTTPS, TLS |
| User access limit |
: |
Max. 30 simultaneous accesses (max. 10 users in JPEG mode or 5 accesses in MPEG-4 mode with HTTPS communication) |
| Buffered images |
: |
*2 Approx. 250 images (320 x 240) •standard image quality •with time display |
| Image transfer method |
: |
SMTP*6, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Sensor, timer or motion detection |
Network Camera |
| Zoom |
: |
10x digital zoom (by area) |
| Viewing angle |
: |
58 ° horizontal 45 ° vertical |
| Pan (horizontal direction) |
: |
— |
| Tilt (vertical direction) |
: |
— |
| Revolving speed |
: |
— |
| Sensor type |
: |
1/4 inch CMOS sensor, approx. 320,000 pixels |
| Lens focal point |
: |
Fixed (focal range: 0.3 m to ∞) |
| Lens brightness |
: |
F2.8 |
| Required light intensity |
: |
5 to 10,000 lux (in color night view mode: 3 to 10,000 lux) |
Audio |
Not Available
Wireless |
Not Available
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
General |
| Operating temperature |
: |
-20°C to +50°C (-4°F to +122°F) |
| Operating humidity |
: |
20% to 90% (No Condensation) |
| Dimensions (H x W x D) |
: |
148 x 108 x 64 mm (5 13/16 x 4 1/4 x 2 1/2 inch) |
| Weight (only the unit) |
: |
495 g (1.09lb.) |
| Power supply (E) |
: |
Input: 220 - 240 V AC output: 9 V DC |
| Power supply (CE) |
: |
Input: 100 - 240 V AC output: 9 V DC |
| Power supply(US) |
: |
Input: 120 V AC output: 9 V DC |
| Consumption |
: |
3.2 W (8.1 W when Light is on) |
| |
| Other Detail |
: |
Built in Light
* Type: 2 White LEDs
* Brightness*3: Directly in front of camera: about 8.5 lux, 20° to left/right of camera: about 2.5 lux |
