| Server |
| Image compression |
: |
JPEG (Motion JPEG) |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 160 x 120 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion) |
| Frame rate |
: |
Max. 7.5 frames/sec (640 x 480); Max. 15 frames/sec (320 x 240, 160 x 120) |
| Security |
: |
User ID/password |
| Supported protocols |
: |
TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP,ICMP, POP3, NTP, UPnPTM |
| User access limit |
: |
Max. 20 simultaneous accesses |
| Buffered images |
: |
Approx. 250 images (320 x 240) •standard image quality •with time display |
| Image transfer method |
: |
SMTP, FTP |
| Image buffer/transfer triggers |
: |
Alarm or motion detection |
Network Camera |
| Zoom |
: |
10x digital zoom (by area) |
| Viewing angle |
: |
53° horizontal 41° vertical |
| Pan (horizontal direction) |
: |
— |
| Tilt (vertical direction) |
: |
— |
| Revolving speed |
: |
— |
| Sensor type |
: |
1/4 inch CMOS sensor, approx. 320,000 pixels |
| Lens focal point |
: |
Fixed (focal range: 0.3 m to ∞) |
| Lens brightness |
: |
F2.8 |
| Required light intensity |
: |
10 to 10,000 lux (in color night view mode : 4 to 10,000 lux) |
Audio |
| Audio communication |
: |
— |
| Audio compression |
: |
— |
| Audio bandwidth |
: |
— |
| Audio input |
: |
— |
| Audio output |
: |
— |
Wireless |
| Standards |
: |
— |
| Antenna |
: |
— |
| Number of channel |
: |
— |
| Transmission speed |
: |
— |
| Security |
: |
— |
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
— |
| Video output |
: |
— |
| Audio output |
: |
— |
| External Microphone Input |
: |
— |
| SD Memory Card slot |
: |
— |
General |
| Operating temperature |
: |
+5°C to +40°C (+41°F to +104°F) |
| Operating humidity |
: |
20% to 80% (no condensation) |
| Dimensions (H x W x D) |
: |
85 x85 x25 mm (3 3/8 x 3 3/8 x 1 inches) |
| Weight (only the unit) |
: |
100 g (0.22 lb) |
| Power supply (E) |
: |
Input: 220-240 V AC, output: 9 V DC |
| Power supply (CE) |
: |
Input: 100-240 V AC, output: 9 V DC |
| Power supply(US) |
: |
Input: 120 V AC, output: 9 V DC |
| Consumption |
: |
1.7 W |
