Camera |
Image Sensor: |
1/4" Super HAD CCD |
Effective Pixels: |
PAL:752(H)×582(V); NTSC:768(H)×494(V) |
Horizontal Resolution: |
Color: 540 TVL, B/W: 570 TVL |
Signal System: |
PAL/NTSC |
Min.illumination: |
Color: 0.2Lux/F14 B/W: 0.02Lux/F1.4 0 Lux with IR |
White Balance: |
Auto / Manual / ATW / Indoor / Outdoor |
AGC: |
Auto/Manual |
S/N Ratio: |
≥ 50dB |
BLC: |
ON/OFF |
Day&Night: |
ICR |
Digital Zoom: |
16x |
Focus Mode: |
Auto / Semi-automatic / Manual |
|
Lens |
Focal Length: |
3.5-105mm, 30X |
Zoom Speed: |
Approx.5.4s(Optical Wide-Tele) |
Angle of View: |
56.4-2.0degree(Wide-Tele) |
Minimum Working Distance: |
10-1,000mm(Wide-Tele) |
Aperture Range: |
F1.4-F3.7 |
|
Pan & Tilt |
Pan Range: |
360° endless |
Pan Speed: |
Pan Manual Speed: 0.1°-160°/s, Pan Preset Speed: 240°/s |
Tilt Range: |
-10°-90° (Auto Flip ) |
Tilt Speed: |
Tilt Manual Speed: 0.1°-120°/s, Tilt Preset Speed: 200°/s |
Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
Number of Preset: |
256 |
Patrol: |
8 patrols, up to 32 presets per patrol |
Pattern: |
4 patterns, with the total recording time not less than 10 min |
Power-off Memory: |
Go to the speed dome last status after reboot |
Park Action: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan |
PTZ Position Display: |
ON/OFF |
Freeze Frame: |
Support |
Password Protection: |
Support |
Zone Scanning/Display: |
Scanning within programmed zone, display zone title |
Camera Title: |
Programmable title display |
Compass: |
Support , the north can be set |
Scheduled Task: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
RS-485 communication diagnosis: |
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
Manchester code communication diagnosis: |
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
|
Infrared |
IR Range: |
80m |
IR irradiation angle: |
Adjustable by zoom |
|
Alarm |
Alarm Input: |
7 inputs, priority configurable |
Alarm Output: |
2 relay outputs, alarm response actions option |
Alarm Actions: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan / Relay output |
|
Input & Output |
Monitor Output: |
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC |
|
Fiber Interface(available for fiber dome only) |
Data Mode: |
1-channel analog video and 1-channel reverse RS-485 data |
Physical Interface: |
FC/SC optional |
Fiber Wavelength: |
1310/1550nm |
Fiber Type: |
Single Fiber/Singlemode |
Transmission Distance: |
20km, 40km / 60km / 80km optional |
|
General |
Menu Language: |
English / Chinese |
RS-485 Protocols: |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
Power Supply: |
24VAC (12V DC optional) |
Power Consumption: |
40W max |
Working Temperature /Humidity: |
-30 ℃-65℃(-22℉-149℉)(outdoor dome) 90% or less |
Protection Level: |
IP66 standard (outdoor dome) TVS 3,000V lightning protection, surge protection and voltage transient protection |
Mounting: |
Various mounting modes option |
Dimensions: |
Φ230.6 ×326.5mm (Φ9.08” ×12.85” ) (Outdoor) |
Weight(approx.): |
5.5kg(12.13Ibs) |
|
