    Brand: Microlexus

    Microlexus MCPO-514

    Rp 11.177.500
    Rp 13.150.000
    tidak termasuk pengiriman
    • 1/4’’ Super HAD CCD
    • Low illumination
    • True day / night
    • 3D intelligent positioning function
    • Powerful PTZ control
    • IP66 rating



    Camera
    Image Sensor:  1/4" Super HAD CCD
    Effective Pixels:  PAL:752(H)×582(V); NTSC:768(H)×494(V)
    Horizontal Resolution:  Color: 540 TVL, B/W: 570 TVL
    Signal System:  PAL/NTSC
    Min.illumination:  0.2Lux/F1.6(Color)
    0.02Lux/F1.6(B/W)
    White Balance:  Auto / Manual / ATW / Indoor / Outdoor
    AGC:  Auto/Manual
    S/N Ratio:  More than 50dB
    BLC:  ON/OFF
    Day&Night:  ICR
    Focus Mode:  Auto / Semi-automatic / Manual
    Lens
    Focal Length:  3.84~88.4 mm, 23X
    Zoom Speed:  Approx.5.1s(Optical
    Wide-Tele)
    Angle of View:  52.2~2.36 degree(Wide~Tele)
    Minimum Working Distance:  10-1200mm(Wide-Tele)
    Aperture Range:  F1.6~F4.5
    Pan & Tilt
    Pan Range:  360° endless
    Pan Speed:  Pan Manual Speed: 0.1°~300°/s,
    Pan Preset Speed: 540°/s
    Tilt Range:  -5°~90° (Auto Flip )
    Tilt Speed:  Tilt Manual Speed: 0.1°~240°/s,
    Tilt Preset Speed: 400°/s
    Proportional Zoom:  Rotation speed can be adjusted automatically according to zoom multiples
    Number of Preset:  256
    Patrol:  8 patrols, each patrol up to 32 presets
    Pattern:  4 patterns, with the total recording time not less than 10 min
    Power-off Memory:  Go to the speed dome last status after reboot
    Park Action:  Call Preset / Patrol / Pattern / Auto Scan / Random Scan / Frame Scan after a pr...
    Password Protection:  Support
    Zone Scanning/Display:  Scanning within programmed zone, display zone title
    Camera Title:  Programmable title display
    Compass:  Support , the north can be set
    Scheduled Task:  Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
    RS-485 communication diagnosis:  Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text
    Manchester code communication diagnosis:  Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text
    Alarm
    Alarm Input:  7 inputs optional
    Alarm Output:  2 relay outputs optional
    Alarm Actions:  Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan / Relay output
    Input & Output
    Monitor Output:  1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
    Fiber Interface(available for fiber dome only)
    Data Mode:  1-channel analog video and 1-channel reverse RS-485 data
    Physical Interface:  FC/SC optional
    Fiber Wavelength:  1310/1550nm
    Fiber Type:  Single Fiber/Singlemode
    Transmission Distance:  20km, 40km / 60km / 80km optional
    General
    Menu Language:  English / Chinese
    RS-485 Protocols:  HIKVISION, Pelco-P, Pelco-D, self-adaptive
    Power Supply:  24VAC (12V DC optional)
    Power Consumption:  15W max(30W max with heater, outdoor dome)
    Working Temperature /Humidity:  -30°C~65°C(-22°F~149°F)(outdoor)
    90% or less
    *(Special specs available for CIS market)
    Protection Level:  IP66 standard (outdoor dome)
    TVS 3000V lightning protection, surge protection and voltage transient protection
    Mounting:  Various mounting modes option
    Dimensions:  Φ220×299.2mm(8.66”×11.78")
    Weight(approx.):  5000g(11.02lbs)



    *
    *
    *
