| Camera |
| Image Sensor: |
1/4"Interline Transfer Super HAD-ⅡCCD |
| Effective Pixels: |
PAL:752(H)×582(V); NTSC:768(H)×494(V) |
| Horizontal Resolution: |
Color: 540 TVL, B/W: 600 TVL |
| Signal System: |
PAL/NTSC |
| Min.illumination: |
Color: 0.2Lux/ (F1.6 AGC ON)
B/W: 0.02Lux/(F1.6 AGC ON) |
| White Balance: |
Auto/ATW/Indoor/Outdoor/One push |
| AGC: |
Auto/Manual |
| S/N Ratio: |
≥ 50dB |
| DNR: |
3D DNR |
| BLC: |
ON/OFF |
| Shutter time: |
PAL: 1/50-1/10,000s, NTSC: 1/60-1/10,000s |
| Day&Night: |
ICR |
| Digital Zoom: |
16x |
| Privacy Masking: |
8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video screen |
| Focus Mode: |
Auto / Semi-automatic / Manual |
|
| Lens |
| Focal Length: |
3.8-45.6mm,12x |
| Zoom Speed: |
Approx.2s(Optical Wide-Tele) |
| Angle of View: |
50.69-4.5degree(Wide-Tele) |
| Minimum Working Distance: |
10-1500mm(Wide-Tele) |
| Aperture Range: |
F1.6-F2.7 |
|
| Pan & Tilt |
| Pan Range: |
360° endless |
| Pan Speed: |
Pan Manual Speed: 0.1° -200°/s,
Pan Preset Speed: 200°/s |
| Tilt Range: |
-2°-90° (Auto Flip ) |
| Tilt Speed: |
Tilt Manual Speed: 0.1°-120°/s,
Tilt Preset Speed: 120°/s |
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
255 |
| Patrol: |
8 patrols, up to 32 presets per patrol |
| Pattern: |
4 patterns, with the total recording time not less than 10 minutes |
| Power-off Memory: |
Support |
| Park Action: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Frame Scan / Random scan / Panorama scan |
| PTZ Position Display: |
ON/OFF |
| Freeze Frame: |
Support |
| Password Protection: |
Support |
| Zone Scanning/Display: |
Scanning within programmed zone, display zone title |
| Camera Title: |
Programmable title display |
| Compass: |
Support , the north can be set |
| Scheduled Task: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| RS-485 communication diagnosis: |
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
| Manchester code communication diagnosis: |
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
|
| Alarm |
| Alarm Input: |
2 inputs |
| Alarm Output: |
1 relay outputs, alarm response actions option |
| Alarm Actions: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan / Relay output |
|
| Input & Output |
| Monitor Output: |
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC |
|
| General |
| Menu Language: |
English / Chinese |
| RS-485 Protocols: |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Supply: |
24VAC (12V DC optional) |
| Power Consumption: |
Max.18 W |
| Working Temperature /Humidity: |
-10℃-50℃(14℉-122℉)(indoor dome )
90% or less |
| Protection Level: |
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting: |
Various mounting modes option |
| Dimensions: |
Φ165×172.5mm(Φ6.50”×6.79”) (Indoor) |
| Weight(approx.): |
3Kg(6.61Ibs) (Indoor) |
| Mount Option: |
Long-arm wall mount: DS-1618ZJ;
Long-arm pendant mount: DS-1662ZJ; Short-arm pendant mount: DS-1661ZJ; |
|
