| Camera |
| Image Sensor: |
1/4" Super HAD CCD |
| Effective Pixels: |
PAL:752(H)×582(V); NTSC:768(H)×494(V) |
| Horizontal Resolution: |
Color: 540 TVL, B/W: 570 TVL |
| Signal System: |
PAL/NTSC |
| Min.illumination: |
0.2Lux/F1.6(Color)
0.02Lux/F1.6(B/W) |
| White Balance: |
Auto / Manual / ATW / Indoor / Outdoor |
| AGC: |
Auto/Manual |
| S/N Ratio: |
More than 50dB |
| BLC: |
ON/OFF |
| Day&Night: |
ICR |
| Focus Mode: |
Auto / Semi-automatic / Manual |
|
| Lens |
| Focal Length: |
3.84~88.4 mm, 23X |
| Zoom Speed: |
Approx.5.1s(Optical
Wide-Tele) |
| Angle of View: |
52.2~2.36 degree(Wide~Tele) |
| Minimum Working Distance: |
10-1200mm(Wide-Tele) |
| Aperture Range: |
F1.6~F4.5 |
|
| Pan & Tilt |
| Pan Range: |
360° endless |
| Pan Speed: |
Pan Manual Speed: 0.1°~300°/s,
Pan Preset Speed: 540°/s |
| Tilt Range: |
-5°~90° (Auto Flip ) |
| Tilt Speed: |
Tilt Manual Speed: 0.1°~240°/s,
Tilt Preset Speed: 400°/s |
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
256 |
| Patrol: |
8 patrols, each patrol up to 32 presets |
| Pattern: |
4 patterns, with the total recording time not less than 10 min |
| Power-off Memory: |
Go to the speed dome last status after reboot |
| Park Action: |
Call Preset / Patrol / Pattern / Auto Scan / Random Scan / Frame Scan after a pr... |
| Password Protection: |
Support |
| Zone Scanning/Display: |
Scanning within programmed zone, display zone title |
| Camera Title: |
Programmable title display |
| Compass: |
Support , the north can be set |
| Scheduled Task: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| RS-485 communication diagnosis: |
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
| Manchester code communication diagnosis: |
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in text |
|
| Alarm |
| Alarm Input: |
7 inputs optional |
| Alarm Output: |
2 relay outputs optional |
| Alarm Actions: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan / Relay output |
|
| Input & Output |
| Monitor Output: |
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC |
|
| Fiber Interface(available for fiber dome only) |
| Data Mode: |
1-channel analog video and 1-channel reverse RS-485 data |
| Physical Interface: |
FC/SC optional |
| Fiber Wavelength: |
1310/1550nm |
| Fiber Type: |
Single Fiber/Singlemode |
| Transmission Distance: |
20km, 40km / 60km / 80km optional |
|
| General |
| Menu Language: |
English / Chinese |
| RS-485 Protocols: |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Supply: |
24VAC (12V DC optional) |
| Power Consumption: |
15W max(30W max with heater, outdoor dome) |
| Working Temperature /Humidity: |
-10°C~50°C(14°F~122°F)(indoor)
90% or less
*(Special specs available for CIS market) |
| Protection Level: |
IP66 standard (outdoor dome)
TVS 3000V lightning protection, surge protection and voltage transient protection |
| Mounting: |
Various mounting modes option |
| Dimensions: |
Φ220×299.2mm(8.66”×11.78") |
| Weight(approx.): |
5000g(11.02lbs) |
|
