Image Sensor
|
1/3" Progressive Scan CMOS |
|
Effective Pixels
|
1320K pixels |
|
Min.Illumination
|
Color: 0.05lux( F1.4, AGC ON); 0 lux with IR B/W: 0.01lux( F1.4, AGC ON); 0 lux with IR |
|
White Balance
|
Auto / Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
|
AGC
|
Auto / Manual |
|
S/N Ratio
|
≥ 50dB |
|
Digital Noise Reduction
|
3D DNR |
|
Backlight Compensation
|
HLC/BLC |
|
Wide Dynamic Range
|
Digital WDR |
|
Shutter speed
|
1 ~ 1/10,000s |
|
Day/Night
|
IR Cut Filter |
|
Digital Zoom
|
16X |
|
Privasi masking
|
2 privacy masks programmable |
|
Focus mode
|
Auto / Semiautomatic / Manual |
|
Focal length
|
4.7 ~ 94.0mm, 20x |
|
Zoom Speed
|
Approx 3s(Optical Wide-Tele) |
|
Angle of View
|
58.3 ~ 3.2 degree (Wide-Tele) |
|
Min. working distance
|
10 ~ 1,000mm(Wide-Tele) |
|
Aperture range
|
F1.4 ~ F3.5 |
|
Pan / Tilt Range
|
Pan: 360° endless; Tilt: -15° ~ 90° (Auto Flip |
|
Pan / Tiltr speed
|
Pan Manual Speed: 0.1° ~ 160°/s,Pan Preset Speed: 240°/s Tilt Manual Speed: 0.1° ~ 120°/s,Tilt Preset Speed: 200°/s |
|
Proportional zoom
|
Rotation speed can be adjusted automatically according to zoom multiples |
|
Number of preset
|
256 |
|
Park action
|
Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan |
|
Patrol
|
8 patrols, up to 32 presets per patrol |
|
Power-off memory
|
Support |
|
PTZ position display
|
Support |
|
Preset freezing
|
Support |
|
Scheduled task
|
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan/Dome reboot/Self-test action/Alarm output |
|
IR distance
|
Up to 100m |
|
IR intensity
|
Automatically adjusted, depending on the zoom ratio |
|
Audio Input
|
1 Mic in/Line in interface, Line input: 2 ~ 2.4V[p-p]; output impedance: 1KΩ, ±10% |
|
Audio Output
|
1 Audio output interface, Line level, impedance: 600Ω |
|
Ethernet
|
10Base-T / 100Base-TX, RJ45 connector |
|
Max. Resolution
|
1280×960 |
|
Frame Rate
|
50Hz:25fps(1280×960), 25fps (1280×720) 60Hz:30fps(1280×960), 30fps (1280×720) |
|
Image compression
|
H.264/MJPEG |
|
Audio Compression
|
G.711u /G.711a /G.726 /MP2L2 |
|
Protocol
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
|
Simultaneous live view
|
Up to 6 |
|
Stream
|
Dual streams |
|
Mini SD Memory Card
|
Micro SD slot, up to 32GB |
|
User/Host Leve
|
Up to 32 users, 3 Levels: Administrator, Operator, User |
|
Security measures
|
User authentication (ID and PW), Host authentication (MAC address), IP address filtering |
|
Web Browser
|
IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+ |
|
Power
|
-A: 24 VAC, max. 30W -AE: High-PoE & 24 VAC, max. 30W |
|
Working temperature
|
-30°C ~ 65°C(-22°F ~ 149°F) |
|
Humidity
|
90% or less |
|
Protection level
|
IP66 TVS 4,000V lightning protection, surge protection and voltage transient protection |
|
Dimension
|
Φ220 × 353.4mm (Φ8.66” × 13.91”) |
|
Weight
|
5.5kg(12.13Ibs) |
