| Camera |
| Image Sensor: |
1/3" Progressive Scan CMOS |
| Min. Illumination: |
0.01 lux @F1.2, AGC ON, 0 lux with IR
0.028 lux @F2.0, AGC ON, 0 lux with IR |
| Shutter time: |
1/25s ~ 1/100,000s |
| Lens: |
6mm @F2.0 (4mm, 12mm optional)Angle of view: 45.3° |
| Lens Mount: |
M12 |
| Day& Night: |
IR cut filter with auto switch |
| Digital noise reduction: |
3D DNR |
|
| Compression Standard |
| Video Compression: |
H.264 / MPEG4 / MJPEG |
| Bit Rate: |
32 Kbps ~ 16 Mbps |
|
| Image |
| Max. Image Resolution: |
1280x960 |
| Frame Rate: |
50Hz: 25fps (1280 × 960), 25fps (1280 x 720)
60Hz: 30fps (1280 × 960), 30fps (1280 x 720) |
| Image Settings: |
Saturation, brightness, contrast adjustable through client software or web browser |
| BLC: |
Yes, zone configurable |
|
| Network |
| Network Storage: |
NAS (iSCSI optional) |
| Alarm Trigger: |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols: |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP,
802.1x, Qos (SIP, SRTP, IPv6 optional) |
| Security: |
User authentication, watermark |
| System Compatibility: |
ONVIF, PSIA, CGI |
|
| Interface |
| Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
|
| General |
| Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: |
max. 5W |
| Weather Proof: |
IP66 |
| IR Range: |
Up to 30m |
| Dimensions: |
60.4 x 76.5 x 138.1mm |
| Weight: |
300g |
|
