Brand: CP Plus

CP Plus CP-UNC-VY20ZL2C

Rp 13.900.000

tidak termasuk pengiriman

1/3” 2Megapixel progressive scan CCD
H.264 & MJPEG dual-stream encoding
25/[email protected](1920×1080)
DWDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
3~9mm varifocal motorized lens
Built-in 2/1 alarm in/out
IR Range of 20 m
Micro SD memory, IP66, IK10, PoE
Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specification :

Image Sensor
1/3” 2Megapixel PS CCD
Minimum Illumination
0.2lux/F1.2
Shutter Speed
Auto/Manual 1/3~1/10000
White Balance
Auto
AGC control
Auto/Manual
Back Light Comp.
BLC / HLC / DWDR
Lens
3~9mm varifocal motorized lens
S/N Ratio
more than 50db
Video Compression
H.264 / MJPEG
Video Streaming
Main Stream: 1080P/720P(1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25/30fps)
Resolution
1080P(1920×1080) / 720P(1280×720) /D1(704×576) / CIF(352×288)
Video Output
1 channel BNC(1.0Vp-p, 75Ω)
Privacy Masking
Up to 4 areas
ICR
Auto(ICR) / Color / B/W
Smart Phone
iPhone, iPad, Android, Windows Phone
Audio Input
1 Ch.
Audio Output
1 Ch.
Audio Compression
G.711a / G.711u (64kbps)/ PCM(128kbps)
Alarm IN
1 channel
Alarm Out
1 channel
Interface
RJ-45 (10/100Base-T)
Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour. ONVIF Ver. 2.0
User Account
10 users
Micro SD
Micro SD, Max 32GB
Operating Temperature
-10°C~+60°C, 10%~90%
Power Source
DC12V/AC24V, PoE(802.3af)
Power Consumption
<10W
Weatherproof Standard
IK10 & IP66
Regulatory
CE FCC & RoHs
Dimension
Φ151mm×119mm
Weight
1.25kg

Namamu *

Email Anda *

Pertanyaan *

Specification :

Image Sensor
1/3” 2Megapixel PS CCD
Minimum Illumination
0.2lux/F1.2
Shutter Speed
Auto/Manual 1/3~1/10000
White Balance
Auto
AGC control
Auto/Manual
Back Light Comp.
BLC / HLC / DWDR
Lens
3~9mm varifocal motorized lens
S/N Ratio
more than 50db
Video Compression
H.264 / MJPEG
Video Streaming
Main Stream: 1080P/720P(1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25/30fps)
Resolution
1080P(1920×1080) / 720P(1280×720) /D1(704×576) / CIF(352×288)
Video Output
1 channel BNC(1.0Vp-p, 75Ω)
Privacy Masking
Up to 4 areas
ICR
Auto(ICR) / Color / B/W
Smart Phone
iPhone, iPad, Android, Windows Phone
Audio Input
1 Ch.
Audio Output
1 Ch.
Audio Compression
G.711a / G.711u (64kbps)/ PCM(128kbps)
Alarm IN
1 channel
Alarm Out
1 channel
Interface
RJ-45 (10/100Base-T)
Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour. ONVIF Ver. 2.0
User Account
10 users
Micro SD
Micro SD, Max 32GB
Operating Temperature
-10°C~+60°C, 10%~90%
Power Source
DC12V/AC24V, PoE(802.3af)
Power Consumption
<10W
Weatherproof Standard
IK10 & IP66
Regulatory
CE FCC & RoHs
Dimension
Φ151mm×119mm
Weight
1.25kg

Produk-produk terkait

CP Plus CP-UNC-TP13FL2CD

Rp 10.000.000 tidak termasuk pengiriman

1/3” 1.3MP Progressive scan CMOS
H.264 & MJPEG dual-stream encoding
Max 25/[email protected](1280×960)&25/[email protected](1280×720)
WDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
2.8~12mm varifocal lens
Built-in 2/1 alarm in/out
Max. IR LEDs length 20m
Micro SD memory, IP66, PoE
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-TP13L3C

Rp 4.700.000 tidak termasuk pengiriman

1/3” 1.3MP PS CMOS Image Sensor
H.264 & MJPEG dual-stream encoding
Max 25/[email protected](1280×960) and 25/[email protected](1280×720)
Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
6mm fixed Lens (3.6mm, 8mm optional)
IR Range of 30Mtr.
IP66, PoE
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-TY20FL2C

Rp 11.900.000 tidak termasuk pengiriman

1/3” 2.0 Megapixel Exmor CMOS Image Sensor
H.264 & MJPEG dual-stream encoding
25/[email protected](1920×1080)
DWDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
3.3-12mm varifocal lens
IR Range max upto 20M
Built-in 2/1 alarm in/out
Supports PoE and IP66 Rating Vandal Proof
Max 32GB Micro SD Card for Local Storage
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-TY20L2C

Rp 6.500.000 tidak termasuk pengiriman

1/3” 2Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
25/[email protected](1920×1080)
H.264 Video Compression and JPEG Image Capture
DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC
IR Range max upto 20M
6mm fixed lens (3.6mm,8mm optional)
Supports PoE and IP66 Rating
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-TY20ZL2C
