Brand: CP Plus

CP Plus CP-UNC-TY20L2C

Rp 6.500.000

tidak termasuk pengiriman

1/3” 2Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
25/30fps@1080P(1920×1080)
H.264 Video Compression and JPEG Image Capture
DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC
IR Range max upto 20M
6mm fixed lens (3.6mm,8mm optional)
Supports PoE and IP66 Rating
Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 2Megapixel Exmor CMOS
Minimum Illumination	0. 1Lux/F1.2 (Color), 0.01Lux/F1.2(B/W);0Lux/F1.2(IR on)
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	6mm (3.6mm,8mm)
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1080P(1920×1080) / 720P(1280×720) / D1(704×576) / CIF(352×288)
Video Streaming	Main Stream: 1.3M/720P(1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25/30fps)
Privacy Masking	Up to 4 areas
ICR	Auto(ICR) / Color / B/W
Regulatory	CE, FCC and RoHS
User Account	10 users
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
IR	IR Range max upto 20 Mtrs
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE(802.3af)
Power Consumption	<6W
Weatherproof Standard	IP66
Dimension	Φ63.5mm×160mm
Weight	0.4kg
Back Light Comp.	BLC / HLC / DWDR

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 2Megapixel Exmor CMOS
Minimum Illumination	0. 1Lux/F1.2 (Color), 0.01Lux/F1.2(B/W);0Lux/F1.2(IR on)
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	6mm (3.6mm,8mm)
S/N Ratio	more than 50 dB
Video Compression	H.264/MJPEG
Resolution	1080P(1920×1080) / 720P(1280×720) / D1(704×576) / CIF(352×288)
Video Streaming	Main Stream: 1.3M/720P(1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25/30fps)
Privacy Masking	Up to 4 areas
ICR	Auto(ICR) / Color / B/W
Regulatory	CE, FCC and RoHS
User Account	10 users
Interface	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
IR	IR Range max upto 20 Mtrs
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE(802.3af)
Power Consumption	<6W
Weatherproof Standard	IP66
Dimension	Φ63.5mm×160mm
Weight	0.4kg
Back Light Comp.	BLC / HLC / DWDR
