Brand: CP Plus

CP Plus CP-MY22CL10-E

Rp 28.000.000

tidak termasuk pengiriman

• 1/4" Ex-View HAD CCD
• Horizontal Resolution of 540 TVL
• 22x Optical Zoom
• Wide Tilt range: +45°~-90°
• IP 66 weather proof
• Long IR coverage of 100 meters
• Vibration proof design
• Revolutionary integrated and stylish design provides a high wind resistance
• GB/T17626.5-1999 Level 4 Surge protection

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4" Ex-View HAD CCD
Pixels	PAL: 795Hx596V, NTSC: 768H×494V
Resolution	540 TVL
Min. Illumination	0.7 lux@F1.2
S/N Ratio	more than 50dB
Electronic Shutter	1/50(1/60) - 1/100000 Sec
Iris Control	Yes
Zoom Optical	22x
Zoom Digital	12x
Lens	3.9~85.8 mm
Focus Mode	Auto / Manual
Gamma	0.45
White Balance (AWB)	ON / OFF Selectable
Gain Control (AGC)	ON / OFF Selectable
Back Light Comp.	ON / OFF Selectable
Day & Night (ICR)	Yes
IR LED	High Power LED
Night Vision Range	100 meters
Special Functions	OSD, Camera Title, Mirror, Privacy Mask = 8, Anti Vibration Housing, Auto Scan, Auto Cruise, Pattern
Pan Range	360 ° Continuous
Pan Speed	0.1°/s ~ 60°/s
Tilt Range	90° ~ 45°
Tilt Speed	0.1°/s ~ 60°/s
Proportional Pan / Tilt Control	Yes
Number of Presets	80
Surge Protection	Yes
Alarm	Yes
Fan & Heater	Yes
Communication	RS 485, Protocol: Pelco-P/D, Baud Rate: 2400~19200 bps
Sync. System	Internal
Video Output	1.0 Vp-p/75W
Power Supply	AC24+=25% / DC12V
Power Consumption	60W
IP Rating	IP66
Dimensions	400 x 320 x 280
Weight	11.0 Kg
Operating Temp	-35~60 °C
Certifications	CE/FCC

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/4" Ex-View HAD CCD
Pixels	PAL: 795Hx596V, NTSC: 768H×494V
Resolution	540 TVL
Min. Illumination	0.7 lux@F1.2
S/N Ratio	more than 50dB
Electronic Shutter	1/50(1/60) - 1/100000 Sec
Iris Control	Yes
Zoom Optical	22x
Zoom Digital	12x
Lens	3.9~85.8 mm
Focus Mode	Auto / Manual
Gamma	0.45
White Balance (AWB)	ON / OFF Selectable
Gain Control (AGC)	ON / OFF Selectable
Back Light Comp.	ON / OFF Selectable
Day & Night (ICR)	Yes
IR LED	High Power LED
Night Vision Range	100 meters
Special Functions	OSD, Camera Title, Mirror, Privacy Mask = 8, Anti Vibration Housing, Auto Scan, Auto Cruise, Pattern
Pan Range	360 ° Continuous
Pan Speed	0.1°/s ~ 60°/s
Tilt Range	90° ~ 45°
Tilt Speed	0.1°/s ~ 60°/s
Proportional Pan / Tilt Control	Yes
Number of Presets	80
Surge Protection	Yes
Alarm	Yes
Fan & Heater	Yes
Communication	RS 485, Protocol: Pelco-P/D, Baud Rate: 2400~19200 bps
Sync. System	Internal
Video Output	1.0 Vp-p/75W
Power Supply	AC24+=25% / DC12V
Power Consumption	60W
IP Rating	IP66
Dimensions	400 x 320 x 280
Weight	11.0 Kg
Operating Temp	-35~60 °C
Certifications	CE/FCC

Produk-produk terkait

CP Plus CP-UNC-TY30FL2C

Rp 12.000.000 tidak termasuk pengiriman

1/2.8” 3.0 Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3.0M(2048×1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
IR Range max upto 20M
3.3~12mm varifocal lens
Built-in 2/1 alarm in/out
Supports PoE and IP66 Rating
Max 32GB Micro SD Card for Local Storage
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-TY30FL3C

Rp 14.100.000 tidak termasuk pengiriman

1/2.8” 3.0 Megapixel progressive scan Exmor CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3.0M(2048×1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
8~16mm varifocal lens
Built-in 2/1 alarm in/out
Max. IR LEDs length 30m
Max 32GB Micro SD Card for Local Storage
IP66, PoE
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-VP13FC

Rp 8.000.000 tidak termasuk pengiriman

1/3” 1.3MP PS CMOS Image Sensor
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1.3M(1280×960) and 25/30fps@720P(1280×720)
Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
2.8~12mm varifocal lens
Built-in 1/1 alarm in/out
Micro SD memory, IP66, IK10, PoE
Mobile Software: CMOB CMS Software: IPSS

CP Plus CP-UNC-VP13FCD

Rp 9.800.000 tidak termasuk pengiriman

1/3” 1.3Megapixel PS CMOS Image Sensor
H.264 & MJPEG dual-stream encoding
Max 25/30fps@1.3M(1280×960) and 25/30fps@720P(1280×720)
WDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
2.8~12mm varifocal lens
Built-in 1/1 alarm in/out
Micro SD memory, IP66, IK10, PoE
Mobile Software: CMOB
CMS Software: IPSS

CP Plus CP-UNC-VP13FL2C
