Specifications
|
| Image Sensor |
1/2.8” 3.0 Megapixel progressive scan Exmor CMOS |
| Minimum Illumination |
0.2LUX/F1.4, 0Lux/F1.2(IR on) |
| Shutter Speed |
Auto/Manual, 1/3~1/10000s |
| White Balance |
Auto |
| AGC control |
Auto/Manual |
| Back Light Comp. |
BLC / HLC / DWDR |
| S/N Ratio |
more than 50 dB |
| Video Compression |
H264/ MJPEG |
| Resolution |
3.0M(2048×1536) / 1080P(1920×1080) /720P(1280×720) / D1(704×576) /CIF(352×288) |
| Video Output |
1 channel BNC(1.0Vp-p, 75Ω) |
| IR |
IR Range max upto 20 Mtrs |
| ICR |
Auto(ICR) / Color / B/W |
| Lens |
3~9mm motorized |
| Privacy Masking |
Up to 4 areas |
| Interface |
RJ-45 (10/100Base-T) |
| Protocol |
HTTP,TCP/IP,ARP,IGMP ,ICMP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PPPOE,UPNP,NTP,Bonjour,SNMP |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Operating Temperature |
-10°C~+60°C, 10%~90% |
| Power Source |
DC12V(AC24V optional), PoE |
| Power Consumption |
Max 10W |
| Weatherproof Standard |
IP66 |
| Dimension |
ф104 mm × 306.7 mm |
| Weight |
1.25Kg |
| Micro SD |
Max 32GB |
| User Account |
10 users |
| Alarm IN |
2 Ch. |
| Alarm Out |
1 Ch. |
| Audio Input |
1 channel |
| Audio Output |
1 channel |
| Audio Compression |
G.711a / G.711u(64kbps) / PCM(128kbps) |
| Regulatory |
CE FCC & RoHs |
| Video Streaming |
Main Stream: 3M(1~20fps)/1080P/720P(1 ~ 25/30fps), Sub Stream: D1/CIF(1 ~ 25/30fps) |
Snapshot
|
Fastest 1fps JPEG capture |
| Auto Iris |
Supported |
