    Brand: CP Plus

    CP Plus CP-UAP-SC23C

    Rp 8.700.000
    tidak termasuk pengiriman
    1/4" CMOS
    High resolution of 540TVL
    Min. Illumination of 0.5Lux(Color) & 0.05Lux(B/W)Powerful 23x optical zoom
    Day/Night (ICR), 2D-DNR, Auto iris, Auto focus, AWB, AGC, BLC
    Max 300 °/s pan speed, 360° continuous pan rotation and auto flip with no blind spot monitor
    Upto 255 Presets, 5 Auto Pattern, 8 Auto Tour, 5 auto scan
    Auto recognition of general protocols Pelco-P/D
    Auto restore to previous PTZ and lens status after power failure
    IP66 all-environments protection, 4000V thunder-proof, auto constant temperature & anti-fog

    Specifications

    Image Sensor 1/4" CMOS
    Pixels 640H) × 480(V)
    Resolution 540 TVL
    Min. Illumination 0.5 Lux@F1.6
    S/N Ratio more than 50dB
    Electronic Shutter 1/50s~1/10,000s
    Special Functions 4000V thunder and wave protection
    Zoom Optical 23x
    Tilt Range Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
    Lens 3.9 ~ 89.7 mm
    Pan Range Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
    Number of Presets 255
    Preset Speed Horizontal: 300°/s, Vertical: 180°/s
    Surge Protection yes
    Alarm Input: 2, Output: 1
    Video Output CVBS: 1.0Vp-p / 75Ω
    Power Supply AC 24V/1.5A(±10%)
    Power Consumption 15W(Indoor), 27W(Outdoor, heater on)
    IP Rating IP66
    Dimensions Φ222(mm) x 322(mm)
    Weight 5.0kg
    Operating Temp -40ºC ~ 60ºC
    Certifications CE, FCC and RoHS
    White Balance (AWB) Auto / Manual
    Gain Control (AGC) Auto / Manual
    Back Light Comp. ON/OFF
    Day & Night (ICR) Yes
    *
    *
    *

    Specifications

    Image Sensor 1/4" CMOS
    Pixels 640H) × 480(V)
    Resolution 540 TVL
    Min. Illumination 0.5 Lux@F1.6
    S/N Ratio more than 50dB
    Electronic Shutter 1/50s~1/10,000s
    Special Functions 4000V thunder and wave protection
    Zoom Optical 23x
    Tilt Range Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
    Lens 3.9 ~ 89.7 mm
    Pan Range Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
    Number of Presets 255
    Preset Speed Horizontal: 300°/s, Vertical: 180°/s
    Surge Protection yes
    Alarm Input: 2, Output: 1
    Video Output CVBS: 1.0Vp-p / 75Ω
    Power Supply AC 24V/1.5A(±10%)
    Power Consumption 15W(Indoor), 27W(Outdoor, heater on)
    IP Rating IP66
    Dimensions Φ222(mm) x 322(mm)
    Weight 5.0kg
    Operating Temp -40ºC ~ 60ºC
    Certifications CE, FCC and RoHS
    White Balance (AWB) Auto / Manual
    Gain Control (AGC) Auto / Manual
    Back Light Comp. ON/OFF
    Day & Night (ICR) Yes
