    CP Plus CP-UNC-TP13FL2CD

    Rp 10.000.000
    tidak termasuk pengiriman
    1/3” 1.3MP Progressive scan CMOS
    H.264 & MJPEG dual-stream encoding
    Max 25/30fps@1.3M(1280×960)&25/30fps@720P(1280×720)
    WDR, Day/Night(ICR), 2DNR, Auto iris, AWB, AGC, BLC
    2.8~12mm varifocal lens
    Built-in 2/1 alarm in/out
    Max. IR LEDs length 20m
    Micro SD memory, IP66, PoE
    Mobile Software: CMOB
    CMS Software: IPSS

    Specifications

    Image Sensor 1/3” 1.3Megapixel CMOS
    Minimum Illumination 0. 1Lux/F1.2 (Color), 0.005Lux/F1.2(B/W);0Lux/F1.2(IR on)
    Shutter Speed Auto/Manual 1/3~1/10000
    White Balance Auto
    AGC control Auto/Manual
    Back Light Comp. BLC / HLC / WDR (128dB)
    S/N Ratio more than 50 dB
    Video Compression H.264/MJPEG
    Resolution 1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)/ CIF(352×288)
    Video Output 1 channel BNC(1.0Vp-p, 75Ω)
    IR 20m
    ICR Auto(ICR) / Color / B/W
    Lens 2.8~12mm
    Privacy Masking Up to 4 areas
    Interface RJ-45 (10/100Base-T)
    Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF Ver. 2.0
    Smart Phone iPhone, iPad, Android, Windows Phone
    Operating Temperature -10°C~+60°C, 10%~90%
    Power Source DC12V(AC24 optional), PoE(802.3af)
    Power Consumption <10W
    Weatherproof Standard IP66
    Dimension  ф104mm × 306.7mm
    Weight 1.25Kg
    Micro SD Max 32GB
    User Account 10 users
    Alarm IN 2 Ch.
    Alarm Out 1 Ch.
    Audio Input 1 channel
    Audio Output 1 channel
    Audio Compression G.711a / G.711u(64kbps)/PCM(128kbps)
    *
    *
    *
