Brand: CP Plus

CP Plus CP-UAP-SY23CP

Rp 10.300.000

tidak termasuk pengiriman

1/4" EXviewHAD CCD II
High Resolution of 650TVL
Min. Illumination of 0.01Lux@F1.6
Powerful 23x Optical Zoom
DWDR, Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Max 300°/s pan speed, 360° continuous pan rotation
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Built-in 2/1 alarm I/O
IP66

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4" EXviewHAD CCD II
Pixels	976(H) × 582(V) / 976(H) × 494(V)
Resolution	650TVL
Min. Illumination	0.01 Lux@F1.6
S/N Ratio	more than 50 dB
Electronic Shutter	1/1s ~1/100,000s
Zoom Optical	23x
Privacy Mask	Up to 24 areas
Focus Mode	Auto / Manual
White Balance (AWB)	Auto, ATW, Indoor, Outdoor, Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	BLC / HLC / DWDR
Day & Night (ICR)	Auto(ICR) / Color / B/W
Special Functions	DWDR, Day/Night (ICR), DNR (2D&3D), Auto iris
Pan Range	0° ~ 360° endless
Pan Speed	0.1° ~ 250°/s
Tilt Range	0° ~ 90°, auto flip 180°
Preset Speed	Pan: 300°/s; Tilt:200°/s
Alarm	2/1 channel In/Out
Number of Presets	255
Operating Temp	-40ºC ~ 60ºC / Less than 90% RH
Sync. System	Interlacing
Communication	RS485
Lens	3.9mm ~ 89.7mm
Video Output	BNC(1.0Vp-p/75Ω), PAL / NTSC
Power Supply	AC24V/1.5A (±10%), DC12V optional
Power Consumption	12W, 27W(Heater on)
Zoom Digital	16x
Dimensions	Φ186mm×234mm
Weight	2KG
Angle of View	61.68° ~ 3.06°
IP Rating	IP66, IK10 optional
Close Focus Distance	100mm~1000mm
Idle Motion	Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period
Tilt Speed	0.1° ~150°/s
Power up Action	Auto restore to previous PTZ and lens status after power failure
Time Task	Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/4" EXviewHAD CCD II
Pixels	976(H) × 582(V) / 976(H) × 494(V)
Resolution	650TVL
Min. Illumination	0.01 Lux@F1.6
S/N Ratio	more than 50 dB
Electronic Shutter	1/1s ~1/100,000s
Zoom Optical	23x
Privacy Mask	Up to 24 areas
Focus Mode	Auto / Manual
White Balance (AWB)	Auto, ATW, Indoor, Outdoor, Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	BLC / HLC / DWDR
Day & Night (ICR)	Auto(ICR) / Color / B/W
Special Functions	DWDR, Day/Night (ICR), DNR (2D&3D), Auto iris
Pan Range	0° ~ 360° endless
Pan Speed	0.1° ~ 250°/s
Tilt Range	0° ~ 90°, auto flip 180°
Preset Speed	Pan: 300°/s; Tilt:200°/s
Alarm	2/1 channel In/Out
Number of Presets	255
Operating Temp	-40ºC ~ 60ºC / Less than 90% RH
Sync. System	Interlacing
Communication	RS485
Lens	3.9mm ~ 89.7mm
Video Output	BNC(1.0Vp-p/75Ω), PAL / NTSC
Power Supply	AC24V/1.5A (±10%), DC12V optional
Power Consumption	12W, 27W(Heater on)
Zoom Digital	16x
Dimensions	Φ186mm×234mm
Weight	2KG
Angle of View	61.68° ~ 3.06°
IP Rating	IP66, IK10 optional
Close Focus Distance	100mm~1000mm
Idle Motion	Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period
Tilt Speed	0.1° ~150°/s
Power up Action	Auto restore to previous PTZ and lens status after power failure
Time Task	Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time
