Produk sebelumnyaCP Plus CP-UAP-SY23CL10-EH

Brand: CP Plus

CP Plus CP-UAP-SY23CL6

Rp 14.000.000

tidak termasuk pengiriman

1/4" Super HAD CCD II
High Resolution of 600TVL
Min. Illumination of [email protected] 23x Optical Zoom
Day/Night (ICR), DNR (2D and 3D), D-WDR, Auto iris, Auto focus, AWB, AGC, BLC
Max 240 °/s Pan Speed, 360° Continuous Pan Rotation and Auto Flips with no Blind Spot Monitor
Up to 255 Preset, 5 Auto Scan, 8 Tour, 5 Pattern
Auto Recognition of General Protocols Pelco-P/D
The max. IR Distance is over 60m
OSD and Operation Prompts of Various Languages

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4” Super HAD II CCD
Pixels	PAL: 752(H) x 582(V) NTSC: 768(H) x 494(V)
Resolution	600 TVL
Min. Illumination	0.01 [email protected]
S/N Ratio	more than 50 dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	23x
Iris Control	Auto Iris
Focus Mode	Auto
White Balance (AWB)	AWB(3200to7500K), ATB(2000to10000K), Indoor(3200K), Outdoor(5800K);Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
Special Functions	Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360°endless, Vertical: -15°~90° auto flip 180° to continue monitor
IR LED	The max. IR distance is over 60m
Tilt Range	Horizontal: 0°~360°endless, Vertical: -15°~90° auto flip 180° to continue monitor
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Gamma	0.45
Number of Presets	255
Operating Temp	-40ºC ~ 60ºC
Surge Protection	Yes
Communication	RS485
Lens	3.9mm ~ 89.7mm
Video Output	CVBS: 1.0Vp-p / 75ohm
Power Supply	AC 24V/2.2A (±10%)
Power Consumption	13W(Indoor), 31W(Outdoor, heater on)
Zoom Digital	16x
Dimensions	Φ185(mm) x 299(mm)
Weight	5.0kg
Certifications	CE, FCC and RoHS
IP Rating	IP66

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/4” Super HAD II CCD
Pixels	PAL: 752(H) x 582(V) NTSC: 768(H) x 494(V)
Resolution	600 TVL
Min. Illumination	0.01 [email protected]
S/N Ratio	more than 50 dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	23x
Iris Control	Auto Iris
Focus Mode	Auto
White Balance (AWB)	AWB(3200to7500K), ATB(2000to10000K), Indoor(3200K), Outdoor(5800K);Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
Special Functions	Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360°endless, Vertical: -15°~90° auto flip 180° to continue monitor
IR LED	The max. IR distance is over 60m
Tilt Range	Horizontal: 0°~360°endless, Vertical: -15°~90° auto flip 180° to continue monitor
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Gamma	0.45
Number of Presets	255
Operating Temp	-40ºC ~ 60ºC
Surge Protection	Yes
Communication	RS485
Lens	3.9mm ~ 89.7mm
Video Output	CVBS: 1.0Vp-p / 75ohm
Power Supply	AC 24V/2.2A (±10%)
Power Consumption	13W(Indoor), 31W(Outdoor, heater on)
Zoom Digital	16x
Dimensions	Φ185(mm) x 299(mm)
Weight	5.0kg
Certifications	CE, FCC and RoHS
IP Rating	IP66

Produk-produk terkait

CP Plus CP-UAP-SY37C-EH

Rp 14.200.000 tidak termasuk pengiriman

1/4" Super HAD CCD II
High Resolution of 600TVL
Min. Illumination of 0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
Powerful 37x Optical Zoom
Day/Night (ICR), D-WDR, DNR (2D and 3D), Auto iris, Auto focus, AWB, AGC, BLCMax 240 °/s pan speed, 360° continuous pan rotation & auto flips with no blind spot monitor
Up to 255 preset, 5 auto scan, 8 tour, 5 patternAuto recognition of general protocols Pelco-P/DUnique 3D positioning function
OSD and operation prompts of various languages
IP66 all-environments protection, 4000V thunder-proof

CP Plus CP-UAP-SY37CL10-EH

Rp 22.400.000 tidak termasuk pengiriman

1/4" Super HAD CCD II
High Resolution of 600TVL
Min. Illumination of 0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
Powerful 37x Optical Zoom
Day/Night (ICR), DNR (2D and 3D), Auto iris, Auto focus, AWB, AGC, BLC
Max 240 °/s pan speed, 360° continuous pan rotation & auto flips with no blind spot monitor
Up to 255 preset, 5 auto scan, 8 tour, 5 patternAuto recognition of general protocols Pelco-P/D
The longest distance of the build-in IR lamp is over 100m
Build-in 7/2 channel alarm input/output
OSD and operation prompts of various languages
IP66 all-environments protection, 4000V thunder-proof

CP Plus CP-UAR-0401Q1

Rp 2.350.000 tidak termasuk pengiriman

• Up to 4 Cameras with 1080P Display
• H.264 Dual-Stream Video Compression
• Full channel D1(4CIF) Realtime Recording
• HDMI / VGA / TV Simultaneous Video Output
• Two-way Talk : 1 channel Input, 1 channel Output, BNC
• All channel synchronous realtime playback, GRID interface and smart search
• Support 1 SATA HDD up to 4TB, 2 USB2.0
• Multiple network monitoring : Web viewer, CMS(DSS/PSS) and DMSS

CP Plus CP-UAR-0801M1
