Produk sebelumnyaCP Plus CP-UAP-SY23C-EH

Brand: CP Plus

CP Plus CP-UAP-SY23CL10-EH

Rp 20.000.000

tidak termasuk pengiriman

1/4" Super HAD CCD II
High Resolution of 600TVL
Min. Illumination of 0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
Powerful 23x optical zoom
Day/Night (ICR), DNR (2D and 3D), Auto iris, Auto focus, AWB, AGC, BLC
Max 240 °/s pan speed, 360° continuous pan rotation & auto flips with no blind spot monitor
Up to 255 preset, 5 auto scan, 8 tour, 5 pattern
Auto recognition of general protocols Pelco-P/D
The longest distance of the build-in IR lamp is over 100m
OSD and operation prompts of various languages
Build-in 7/2 channel alarm input/output

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/4” Super HAD II CCD
Pixels	PAL: 752(H) x 582(V) NTSC: 768(H) x 494(V)
Resolution	600 TVL
Min. Illumination	0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
S/N Ratio	Above 50 dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	23x
Iris Control	Auto Iris
Focus Mode	Auto
White Balance (AWB)	AAWB (3000 to 7500K), ATW(2000 to 1000K), Indoor(3200K), Outdoor(5800K), Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
Special Functions	Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
IR LED	Auto / Near light / Far light / OFF, 6 Near light + 8 Far light, up to 100m
Tilt Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Gamma	0.45
Number of Presets	255
Operating Temp	-20ºC ~ 60ºC
Alarm	7/2 alarm input/output, Triggering Preset/Tour/Pattern/Scan/On-off Output
Communication	RS485
Lens	3.9mm ~ 89.7mm
Video Output	CVBS: 1.0Vp-p / 75ohm
Power Supply	AC 24V/3A (±10%)
Power Consumption	12W/30W(IR lamp on)
Zoom Digital	10x
Dimensions	Φ230(mm) x 352(mm)
Weight	7.0kg
Certifications	CE, FCC and RoHS

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/4” Super HAD II CCD
Pixels	PAL: 752(H) x 582(V) NTSC: 768(H) x 494(V)
Resolution	600 TVL
Min. Illumination	0.01 Lux/F1.6(AGC ON,Slow Shutter ON)
S/N Ratio	Above 50 dB
Electronic Shutter	Auto: 1/s~1/100,000s Manual: 1/s~1/10,000s
Zoom Optical	23x
Iris Control	Auto Iris
Focus Mode	Auto
White Balance (AWB)	AAWB (3000 to 7500K), ATW(2000 to 1000K), Indoor(3200K), Outdoor(5800K), Manual
Gain Control (AGC)	Auto / Manual
Back Light Comp.	ON/OFF
Day & Night (ICR)	Yes
Special Functions	Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Pan Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
IR LED	Auto / Near light / Far light / OFF, 6 Near light + 8 Far light, up to 100m
Tilt Range	Horizontal: 0°~360°endless, Vertical: -2°~90° auto flip 180° to continue monitor
Preset Speed	Horizontal: 240° /s, Vertical: 200° /s
Gamma	0.45
Number of Presets	255
Operating Temp	-20ºC ~ 60ºC
Alarm	7/2 alarm input/output, Triggering Preset/Tour/Pattern/Scan/On-off Output
Communication	RS485
Lens	3.9mm ~ 89.7mm
Video Output	CVBS: 1.0Vp-p / 75ohm
Power Supply	AC 24V/3A (±10%)
Power Consumption	12W/30W(IR lamp on)
Zoom Digital	10x
Dimensions	Φ230(mm) x 352(mm)
Weight	7.0kg
Certifications	CE, FCC and RoHS
