Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Baseline Profile (BP) and Main Profile (MP) Motion JPEG |
|
Resolution
|
176 x 120 to 720 x 576 176 x 120 to 1536 x 1152 for quad view |
|
Frame Rate
|
H.264: 15 fps in quad view 30 fps in all other resolutions Motion JPEG: 30 fps in all resolutions |
|
Video Streaming
|
One individually configured H.264 and one Motion JPEG stream per channel at full frame rate More streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth, VBR/CBR H.264 |
|
Image settings
|
Compression, Color, Brightness, Contrast, Text and image overlay, Mirroring of images, Privacy mask, Aspect ratio correction, Enhanced deinterlace filter, Video termination, Anti-aliasing, Temporal noise filtering, Rotation: 90°, 180°, 270° |
|
Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported 100 presets/camera, guard tour, PTZ control queue Supports Windows compatible joysticks |
|
Audio streaming
|
Two-way, full and half duplex (mic/line input 1 or 2/line output) |
|
Audio Compression
|
In: AAC-LC 8 or 16 kHz 8 to 64 kbit/s, G.711 µ-law PCM 8 kHz 64 kbit/s, G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s Out: G.711 µ-law PCM 8 kHz 64 kbit/s, µ-law PCM 16 kHz 128 kbit/s G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s |
|
Audio I/O
|
External microphone input or line input, Line level output Audio streaming, record (AU) and play uploaded (WAV, AU) clips AU (G.711 µ-law 8-bit 8/16 kHz mono), WAV (PCM 16-bit 8/16 kHz mono) 8 input, 4 output |
|
Security
|
Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log |
|
Supported Protocols
|
IPv4/v6, HTTP, HTTPS, QoS layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
|
Intelligent Video
|
Video motion detection, Active tampering alarm, Audio detection |
|
Trigger Events
|
Intelligent video, External inputs, Video loss |
|
Alarm Events
|
File Upload: FTP, HTTP and email Notification: email, HTTP and TCP Video and audio recording to edge storage Pre- and post-alarm video buffering PTZ preset, Play audio clip, External output activation |
|
Data streaming
|
Event data |
|
Built-in installation aids
|
Pixel counter |
|
Casing
|
Metal casing Standalone, rack mount, or wall mount |
|
Processor and Memory
|
4x 512 MB RAM, 4x 128 MB Flash |
|
Power
|
AXIS PS-P power supply |
|
Connectors
|
16 x Analog composite video inputs (BNC) 8 x 3.5 mm audio input sockets, 4 x 3.5 mm audio output sockets 1 x 1000 Base TX Ethernet (RJ45) + 1 x auxiliary Ethernet (RJ45) 1 x Gb/s SFP slot 4 x Terminal block for up to 4 configurable external inputs/outputs 4 x Terminal block for RS485/RS422 serial communication (full duplex) 1 x DC input terminal block |
|
Edge Storage
|
Four microSD/ microSDHC/ microSDXC slots supporting memory cards up to 64 GB (cards not included) Support for recording to network share (network-attached storage or file server |
|
Operating Conditions
|
Temperature: 32 to 122°F (0 to 50°C) Humidity 20 to 80% RH (non-condensing) |
|
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN61000-6-1, EN61000-6-2 FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B UL/IEC/EN 60950-1 |
|
Dimensions (mm)
|
1.73 x 19.00 x 4.50" (43.94 x 482.60 x 114.30 mm) |
|
Weight
|
4.10 lb (1.85 kg) |
