Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported 100 presets/camera, guard tour, PTZ control queue Supports Windows compatible joysticks |
|
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Baseline Profile (BP) and Main Profile (MP) Motion JPEG |
|
Resolution
|
176 x 120 to 720 x 576 176 x 120 to 1536 x 1152 for quad view |
|
Frame Rate
|
H.264: 15 fps in quad view 30 fps in all other resolutions Motion JPEG: 30 fps in all resolutions |
|
Video Streaming
|
Multi-stream H.264 and Motion JPEG: 1 H.264 and 1 JPEG stream on each channel (32 streams in total) in full frame rate individually configured streams in maximum resolution at 30/25 fps; more streams if identical or limited in frame rate/resolution. Controllable frame rate and bandwidth VBR/CBR H.264 |
|
Image settings
|
Compression, color, brightness, contrast Rotation: 90°, 180°, 270° Aspect ratio correction Mirroring of images Text and image overlay Privacy mask Enhanced deinterlace filter Video termination Anti-aliasing Temporal noise filtering |
|
Audio streaming
|
2-way, full duplex and half duplex (mic / line input 1 / line output) 2-way, full duplex and half duplex (mic / line input 2 / line output) |
|
Audio Compression
|
In: AAC-LC 8 or 16 kHz 8-64 kbit/s G.711 μ-law PCM 8 kHz 64 kbit/s G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s Out: G.711 μ-law PCM 8 kHz 64 kbit/s μ-law PCM 16 kHz 128 kbit/s G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s |
|
Audio I/O
|
8 external microphone or line inputs and 4 line outputs |
|
Security
|
Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log |
|
Supported Protocols
|
IPv4/v6, HTTP, HTTPS, QoS layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
|
Application Programming Interface
|
Open API for software integration, including VAPIX Includes the ONVIF specification Support for AXIS Video Hosting System (AVHS) with One-Click Camera connection |
|
Intelligent Video
|
Video motion detection, active tampering alarm |
|
Trigger Events
|
Audio detection |
|
Alarm Events
|
File upload via FTP, HTTP and email Notification via email, HTTP and TCP PTZ preset External output activation Play audio clip Pre- and post-alarm video buffering |
|
Casing
|
Standalone, rackmount or wallmount |
|
Processor and Memory
|
4 x ARTPEC-4, 4 x 512 MB RAM, 4 x 128 MB Flash |
|
Power
|
8-20 VDC, maximum 32 W; 4 x Power over Ethernet IEEE 802.3af Class 3, AXIS PS-P power supply Use the supplied mains adapter or a limited power source, in which rated power output does not exceed either 100 W or 5 A |
|
Connectors
|
16 x analog composite video inputs (BNC) 8 x mono microphone or line inputs, 6Vpp maximum (3.5 mm jacks) 4 x mono audio output, 2Vpp maximum at 1kohm (3.5 mm jack) 4 x 10 BASE-T / 100BASE-TX Ethernet 16 x configurable external inputs/outputs (terminal blocks) 4 x RS-485/422 full duplex (terminal blocks) 1 x DC input terminal block |
|
Local Storage
|
4 x microSD / SDHC |
|
Operating Conditions
|
Temperature: 32 to 122°F (0 to 50°C) Humidity 20 to 80% RH (non-condensing) |
|
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN61000-6-1, EN61000-6-2 FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B UL/IEC/EN 60950-1 |
|
Dimensions (mm)
|
1.77 x 17.32 x 6.5" (45 x 440 x 165 mm) |
|
Weight
|
5.6 lb (2.54 kg) |
