Video Compression
|
H.264 ( MPEG - 4 Part 10/AVC) Baseline and Main Profile Motion JPEG |
|
Resolution
|
176x120 to 720x576, 176x120 to 1536x1152 for quad view |
|
Frame Rate
|
H.264: 30/25 (NTSC/PAL) fps 15 fps in quad view in full resolution Motion JPEG: 30/25 (NTSC/PAL) fps 15 fps in quad view in full resolution |
|
Video Streaming
|
One individually configured H.264 and one Motion JPEG stream per channel at full frame rate More streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth, VBR/CBR H.264 |
|
Image settings
|
Compression, Color, Brightness, Contrast, Aspect ratio correction, Mirroring of images, Text and image overlay, Privacy mask, Enhanced deinterlace filter, Video termination, Anti - aliasing, Temporal noise filtering Rotation: 90°, 180°, 270° |
|
Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported (drivers available for download at www.axis.com) Support for one PTZ driver in each group of 4 channels 100 presets/camera, Guard tour, PTZ control queue Supports Windows compatible joysticks |
|
Security
|
Password protection, IP address filtering, HTTPS a encryption, IEEE 802.1X a network access control, Digest authentication, User access log |
|
Supported standard
|
IPv4/v6, HTTP, HTTPS a , IEEE 802.1X a , QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
|
Application Programming Interface
|
Open API for software integration, including VAPIX®; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One - Click Camera Connection ONVIF Profile S; specification at www.onvif.org |
|
Intelligent Video
|
Video motion detection, Active tampering alarm |
|
Trigger Events
|
Intelligent video, Video loss |
|
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video recording to edge storage Pre - and post - alarm video buffering PTZ preset |
|
Data streaming
|
Event data |
|
Built-in installation aids
|
Pixel counter |
|
Casing
|
Metal casing, Standalone, rackmount or wallmount |
|
Memory
|
4x 512 MB RAM, 4x 128 MB Flash |
|
Power
|
AXIS PS - P power supply 12 V DC, 17 W |
|
Connectors
|
16 x Analog composite video inputs (BNC) 1 x 1000 Base TX Ethernet on RJ45 4 x Terminal blocks for RS422/RS485 serial communication (full duplex) 1 x DC input terminal block |
|
Edge Storage
|
Four microSD/microSDHC/microSDXC slots supporting memory cards up to 64 GB (cards not included) Support for recording to network share (network - attached storage or file server) |
|
Operating Conditions
|
0 °C to 50 °C ( 32 °F to 122 °F) Humidity 20–80% RH (non - condensing) |
|
Approvals
|
EN 55022 Class B, EN 61000 - 3 - 2, EN 61000 - 3 - 3, EN 55024, EN 61000 - 6 - 1, EN 61000 - 6 - 2, FCC Part 15 Subpart B Class B, ICES - 003 Class B, VCCI Class B, C - tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, IEC/EN/UL 60950 - 1 |
|
Weight
|
1850 g ( 4.1 lb) |
|
Included accessories
|
Power supply, Mounting and connector kits (incl. 2 mount brackets and 4 rubber feet), Installation Guide, Installation and Management Software CD, Windows decoder user licenses |
|
Video Management Software
|
XIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
|
Warranty
|
Axis 1 - year warranty and AXIS Extended Warranty option, see www.axis.com/warranty |
