Image Sensor
|
1/4” Progressive scan RGB CMOS VGA |
Lens
|
: 3.0 mm, F2.0, fixed iris Horizontal angle of view: 66° |
Light sensitivity
|
1–100000 lux, F2.0 |
Shutter Time
|
1/5000 s to 1/4 s |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC), Motion JPEG, MPEG-4 Part 2 (ISO/IECV 14496-2) |
Video Resolution
|
640x480 to 160x120 |
Video Framerate
|
30 fps |
Video Streaming
|
Multiple, individually configurable streams in H.264, Motion JPEG and MPEG-4 Part 2 |
Image settings
|
Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at low light, Rotation, Text and image overlay, Privacy mask |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Camera Connection. ONVIF; specification at www.onvif.org |
Intelligent Video
|
Video motion detection, Active tampering alarm |
Trigger Events
|
Intelligent video |
Event actions
|
File upload: FTP, HTTP and email Notification: email, HTTP and TCP Pre- and post-alarm video buffering |
Built-in installation aids
|
Pixel counter |
Casing
|
Metal camera module holder, Plastic camera module casing, Plastic transparent cover and white cover ring |
Memory
|
64 MB RAM, 32 MB Flash |
Power
|
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 1 |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE |
Edge Storage
|
Support for recording to network share (network-attached storage or file server) |
Operating Conditions
|
0 °C to 50 °C (32 °F to 122 °F) |
Approvals
|
55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24, EN/UL 60950-1, MIC Class B |
Weight
|
260 g (0.6 lb) |
Included accessories
|
Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
