Video Compression
|
H.264 Baseline and Main Profiles ( MPEG - 4 Part 10/AVC) Motion JPEG |
|
Resolution
|
720x576 to 176x120, 1536x1152 to 176x120 for quad view |
|
Frame Rate
|
H.264: 15 fps in all resolutions Motion JPEG: 15 fps in all resolutions |
|
Video Streaming
|
One individually configured H.264 and one Motion JPEG stream per channel at 15 fps More streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth VBR/CBR H.264 |
|
Image settings
|
Compression, Color, Brightness, Contrast, Aspect ratio correction, Mirroring of images, Text and image overlay, Privacy mask, Enhanced deinterlace filter, Video termination, Anti - aliasing, Temporal noise filtering Rotation: 90°, 180°, 270° |
|
Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported (drivers available for download at www.axis.com ) Multiple camera presets supported, Guard tour, PTZ control queue Supports Windows compatible joysticks |
|
IP Address
|
One IP address for four channels |
|
Security
|
Password protection, IP address filtering, HTTPS a encryption, IEEE 802.1X a network access control, Digest authentication, User access log |
|
Supported Protocols
|
IPv4/v6, HTTP, HTTPS a , SSL/TLS a , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB - II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
|
Application Programming Interface
|
Open API for software integration, including VAPIX®; specifications at www.axis.com ONVIF Profile S; specification at www.onvif.org |
|
Intelligent Video
|
Video motion detection, Active tampering alarm |
|
Trigger Events
|
Intelligent video, Video loss, Edge storage events |
|
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video recording to edge storage Pre - and post - alarm video buffering PTZ preset |
|
Data streaming
|
Event data |
|
Built-in installation aids
|
Pixel counter |
|
Casing
|
Standalone, metal casing, wall mount |
|
Memory
|
512 MB RAM, 128 MB Flash |
|
Power
|
8–20 V DC, max. 7 W Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3 |
|
Connectors
|
1x DC input terminal block 4x analog composite video BNC inputs RJ45 10BASE - T/100BASE - TX PoE Terminal block for RS - 485/RS - 422 (full duplex) |
|
Edge Storage
|
MicroSD/microSDHC/microSDXC slot supporting memory card up to 64 GB (card not included) Support for recording to dedicated network - attached storage (NAS) |
|
Operating Conditions
|
0 °C to 50 °C ( 32 °F to 122 °F) Humidity 20–80% RH (non - condensing) |
|
Approvals
|
EN 55022 Class B, EN 55024, IEC/EN/UL 60950 - 1, EN 61000 - 3 - 2, EN 61000 - 3 - 3, EN 61000 - 6 - 1, EN 61000 - 6 - 2, FCC Part 15 Subpart B Class B, ICES - 003 Class B, VCCI Class B, C - tick AS/NZS CISPR 22 Class B, KCC KN22 Class B, KN24 |
|
Weight
|
570 g ( 1.26 lb) |
|
Included accessories
|
Power supply, Mounting and connector kits, Installation Guide, Installation and Management Software CD, Windows decoder user licenses |
|
Video Management Software
|
AXIS Camera Companion (included), AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
|
Warranty
|
Axis 1 - year warranty, see www.axis.com/warranty |
