Brand: Axis

Axis 247S

Compact, single channel video server
Powered over Ethernet with power out for the camera
High quality, de-interlaced video
Audio support
Powerful event management

Qty:

Overview
Specifications
Contact Us

AXIS 247S

Jual AXIS 247S harga distributor di JakartaCCTV, jika sistem keamanan Anda menggunakan Camera Analog namun Anda ingin menggunakan sistem keamanan berbasis Internet Protocol (IP), Anda bisa menggunakan AXIS 247S sebagai solusinya. AXIS 247S sebuah Video Server 1 channel yang berkinerja tinggi untuk mengintegrasikan Analog Camera ke sistem Video Pengawasan (suerveilliance) berbasis IP (Internet Protocol). AXIS 247S yang memiliki bentuk yang compact sangat ideal untuk diaplikasikan dekat Analog Camera, dimana kendala utama adalah ruang yang sempit, misalkan untuk video pengawasan (surveilliance) dengan Camera Kecil pada ruangan ATM. AXIS Video Server memberikan Anda kesempatan untuk menikmati keuntungan dari semua manfaat yang ditawarkan teknologi digital, sangat sempurna bagi sistem keamanan yang masih menggunakan Analog Camera namun menggunakan Video Pengawasan (Surveilliance) berbasis IP (Internet Protocol) misalkan di kantor bank, bandara, bangunan pemerintahan atau industry. Jadikan AXIS 247S sebagai salah satu system keamanan pada property Anda dengan mendapatkannya hanya di JakartaCCTV.

Video Server ini dengan cepat dan mudah dipasang di dinding atau langit-langit. Hal ini didukung dengan Power over Ethernet (PoE), yang juga mampu untuk membrikan daya pada Camera dan otomatis menghilangkan kebutuhan untuk outlet listrik. Klasifikasi daya 2 atau 3 yang dapat dipilih, memungkinkan optimalisasi PoE –enable network- baik menyediakan daya yang cukup untuk Camera kecil atau Camera Analog standar. Produk dari AXIS terutama AXIS 247S hanya bisa Anda dapatkan di JakartaCCTV. JakartaCCTV adalah distributor resmi semua produk AXIS yang memberikan Anda penawaran harga special.

FITUR AXIS 247S

Video format MPEG-4 dan MJPEG
Resolusi 720x576 atau 160x120
Video Output Digital atau Analog
Bisa menggunakan Power over Ethernet (PoE) sebagai sumber daya

AXIS 247S hanya bisa Anda dapatkan hanya di JakartaCCTV dengan harga 1 Channel Video Server murah. Kami menyediakan paket CCTV murah dan paket DVR murah mulai dari jual IP camera, jual IR camera, jual Analog camera, jual Dome camera, jual Cube camera, jual Box camera serta jual DVR 4 channels, jual DVR 6 channels, jual DVR 8 channels, jual DVR 12 channels, jual DVR 16 channels, jual DVR 32 channels. Jual1 Channel Video Servermurah di Jakartahanya di JakartaCCTV.

Spesifikasi produk

Video Compression	MPEG-4 Part 2 (ISO/IEC 14496-2) Motion JPEG
Resolution	704x576 to 160x120
Frame Rate	MPEG-4 : Up to 30/25 (NTSC/PAL) fps at 4CIF & MJPEG : Up to 30/25 (NTSC/PAL) fps at VGA, 27/23 fps at 4CIF
Video Streaming	Simultaneous MPEG-4 and Motion JPEG Controllable frame rate and bandwidth VBR/CBR MPEG-4
Image settings	Compression, color , Aspect ratio correction , Text and image overlay , Privacy mask , Deinterlace filter
Audio streaming	One-way
Audio Compression	AAC LC 8 kHz 32 kbit/s , G.711 PCM 64kbit/s , G.726 ADPCM 32 or 24 kbit/s
Audio I/O	External microphone input or line input Line level output
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control
Supported Protocols	IPv4/v6, HTTP, HTTPS, QoS layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® from Axis Communications available at www.axis.com
Intelligent Video	Video motion detection, active tampering alarm, audio detection
Alarm Triggers	Intelligent video, external inputs, video loss
Alarm Events	File upload via FTP, HTTP and email / Notification via email, HTTP and TCP / External output activation
Video Buffer	9 MB pre- and post-alarm
Casing	Metal casing Standalone or with brackets for wall mount
Processor and Memory	ARTPEC A, 32 MB RAM, 8 MB Flash
Power	7 – 15 V DC, max. 5 W or Power over Ethernet IEEE 802.3af Class 2/3
Connectors	Analog composite video BNC input, NTSC/PAL auto-sensing / RJ-45 10BASE-T/100BASE-TX PoE / Power terminal block: Power feed to the camera or alternative / power supply for the video server / I/O Terminal block for 1 alarm input, 1 alarm output / 3.5 mm mic/line in, 3.5 mm line out / 6 pin Mini-DIN alternative connection for: video in, audio in, power out
Operating Conditions	0 – 50 °C (32 – 122 °F) Humidity 20 – 80% RH (non-condensing)
Approvals	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, EN 60950-1
Weight	214 g (0.47 lb)
Included accessories	Terminal connector kit, Installation Guide, CD with installation and management tools, software and User’s Manual, 1 Windows decoder user license
