Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
|
Resolution
|
176x120 to 720x576 |
|
Frame Rate
|
H.264 30/25 (NTSC/PAL) fps in all resolutions & MJPEG 30/25 (NTSC/PAL) fps in all resolutions |
|
Video Streaming
|
Multi-stream H.264 and Motion JPEG: 3 simultaneous, individually configured streams in max. resolution at 30/25 fps; more streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth VBR/CBR H.264 |
|
Image settings
|
Compression, color, brightness, contrast Rotation: 90°, 180°, 270° Aspect ratio correction Mirroring of images Text and image overlay Privacy mask Enhanced deinterlace filter |
|
Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported (drivers available for download at www.axis.com) 100 presets, guard tour, PTZ control queue Supports Windows compatible joysticks |
|
Audio streaming
|
Two way, full duplex |
|
Audio Compression
|
AAC-LC 8 kHz 32 kbit/s, 16 kHz 64 kbit/s G.711 PCM 8 kHz 64 kbit/s G.726 ADPCM 8 kHz 32 or 24 kbit/s |
|
Audio I/O
|
External microphone input or line input Line level output |
|
Security
|
Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log |
|
Supported Protocols
|
IPv4/v6, HTTP, HTTPS, QoS layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, T C P, U D P, I G M P, R T C P, I C M P, D H C P, A R P, S O C K S |
|
Application Programming Interface
|
Open API for software integration, including VAPIX® from Axis Communications available at www.axis.com AXIS Camera Application Platform from Axis Communications; specifications available at www.axis.com Includes the ONVIF specification available at www.onvif.org Support for AXIS Video Hosting System (AVHS) with One-Click Camera connection |
|
Intelligent Video
|
Video motion detection, active tampering alarm, audio detection Support for AXIS Camera Application Platform enabling installation of additional applications |
|
Trigger Events
|
Intelligent video, external inputs, video loss, disk full |
|
Alarm Events
|
File upload via FTP, HTTP and email Notification via email, HTTP and TCP External output activation PTZ presets Local storage |
|
Video Buffer
|
64 MB pre- and post-alarm |
|
Casing
|
Metal casing. Standalone or wall mount |
|
Processor and Memory
|
ARTPEC-3, 128 MB RAM, 128 MB Flash |
|
Power
|
8-20 V DC, max. 7.2 W or Power over Ethernet IEEE 802.3af Class 2/3 |
|
Connectors
|
Analog composite video BNC input, NTSC/PAL auto-sensing RJ-45 10BaseT/100BaseTX PoE DC terminal block: power in 8-20 V DC, max. 7.2 W or power out 12 V DC, max. 5 W I/O terminal block for four configurable inputs/outputs 3.5 mm mic/line in, 3.5 mm line out RS-485/ RS-422 |
|
Local Storage
|
SD/SDHC memory card slot (Card is not included) |
|
Operating Conditions
|
0 °C – 50 °C (32 °F – 122 °F) Humidity 20-80% RH (non-condensing) |
|
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES- 003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, EN 60950-1 Power supply PS-T: EN 60950-1, CSA, C/US Power supply PS-K: EN 60950-1, UL, cUL |
|
Weight
|
335 g (0.7 lb.) |
|
Included accessories
|
Power supply, mounting and connector kits, Installation Guide, CD with installation and management tools, software and User’s Manual, 1 Windows decoder user license |
