Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
|
Resolution
|
NTSC: 720x480 (D1) to 176x120 (QCIF) PAL: 720x576 (D1) to 176x144 (QCIF) |
|
Frame Rate
|
H.264 & MJPEG (30/25 (NTSC/PAL) fps in all resolutions) |
|
Video Streaming
|
Multi-stream H.264 and Motion JPEG: 3 simultaneous, individually configured streams in max. resolution at 30/25 fps; more streams if identical or limited in frame rate/resolution Controllable frame rate and bandwidth VBR/CBR H.264 |
|
Image settings
|
Compression, color, brightness, contrast Rotation: 90°, 180°, 270° Aspect ratio correction Mirroring of images Text and image overlay Privacy mask Enhanced deinterlace filter Video termination Anti-aliasing |
|
Pan/ Tilt/ Zoom
|
Wide range of analog PTZ cameras supported (drivers available for download at www.axis.com) 100 presets/camera, guard tour, PTZ control queue Supports Windows compatible joysticks |
|
Audio streaming
|
Two-way |
|
Audio Compression
|
In: AAC-LC 8 or 16 kHz 8-64 kbit/s, G.711 PCM 8 kHz 64 kbit/s, G.726 ADPCM 8 kHz 32 or 24 kbit/s Out: G.711 PCM 8 kHz 64 kbit/s, μ-law PCM 16 kHz 128 kbit/s, G.726 ADPCM 8 kHz 32 kbit/s or 24 kbit/s |
|
Audio I/O
|
External microphone input or line input (balanced or unbalanced) and line output (unbalanced), Phantom Power |
|
Security
|
Password protection, IP address filtering, HTTPS* encryption, IEEE 802.1X network access control, digest authentication, user access log |
|
Supported Protocols
|
IPv4/v6, HTTP, HTTPS*, QoS layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
|
Application Programming Interface
|
Open API for software integration, including the ONVIF specification available at www.onvif.org, as well as VAPIX® and AXIS Camera Application Platform from Axis Communications, specifications available at www.axis.com Support for AXIS Video Hosting System (AVHS) with One-Click Camera connection |
|
Intelligent Video
|
Video motion detection, audio detection, active tampering alarm Support for AXIS Camera Application Platform enabling installation of additional applications |
|
Trigger Events
|
Intelligent video, external inputs, video loss, audio detection |
|
Alarm Events
|
File upload via FTP, HTTP and email Notification via email, HTTP and TCP PTZ preset External output activation Play audio clip Pre- and post-alarm video buffering |
|
Processor and Memory
|
4x ARTPEC-3, 4x 256 MB RAM, 4x 128 MB Flash |
|
Power
|
12 V DC, max. 13.0 W |
|
Connectors
|
4 analog composite video BNC inputs 4 3.5 mm jacks for mono microphone or line input (max. 6 Vpp) and mono line output (typical 1.8 Vpp at 1 kohm) 10BASE-T/100BASE-TX/1000BASE-T Ethernet 8 configurable external inputs/outputs Up to 4 RS-485/RS-422 half duplex, depending on the rack |
|
Operating Conditions
|
0 °C to 45 °C (32 °F to 113 °F) Humidity 20-80% RH (non-condensing) |
|
Approvals
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN61000-6-1, EN61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class A, UL/IEC/EN 60950-1 |
|
Weight
|
229 g (0.50 lb.) |
|
Included accessories
|
Installation Guide, CD with installation tools, recording software and User’s Manual, 4 Windows decoder 1-user license |
