Camera
|
Image Sensor |
1/3 type interline transfer CCD |
Effective Pixels |
976 (H) x 582 (V) |
Scanning Mode |
2:1 interlace |
Scanning Area |
4.8 mm (H) x 3.6 mm (V) {3/16 inches(H) x 1/8 inches(V) } |
Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
Horizontal Resolution |
650 TV lines (typ.) |
Minimum Illumination |
Color : 0.08 lx(color mode) B/W: 0.008 lx (black-and-white mode, LED OFF) B/W: 0 lx (black-and-white mode, LED ON |
Signal-to-Noise Ratio |
52 dB (AGC: OFF |
White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K |
Light Control |
ALC/ALC+/ELC |
BLC |
ON / OFF |
ABS |
ON / OFF |
AGC |
ON (LOW, MID, HIGH) / OFF |
Electronic Shutter |
- |
Electronic Sensitivity UP |
32x max. AUTO, 512x max. FIX |
Day Night (IR) |
AUTO1 / AUTO2 / ON / OFF |
LED |
OFF / AUTO / FIX (available for D&N AUTO2 mode or D&N ON mode |
Digital Noise Reduction |
high or low |
Scene File |
2 patterns |
Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
Privacy Zone |
ON(1) / ON(2) / OFF |
Image Stabilizer |
ON / OFF |
Auto Focus |
Lens AF / MANUAL |
IR LED irradiation distance |
20 m |
Synchronization |
Internal (INT) |
Lens
|
Focal Length |
2.8 mm ~ 10.0 mm |
Zoom Ration |
3.6x |
Angular Field of View |
H: 100° 50' (Wide) ~ 27° 39'(Tele) V: 73° 51' (Wide) ~ 20° 45' (Tele) |
Maximum Aperture Ratio |
F1.3 (Wide) ~ F3.1 (Tele |
Focusing Range |
0.3 m ~ ∞ |
Input / Output
|
Video Output |
1.0 V [p-p] / PAL composite 75 |
Controller Interface |
Coaxial Multiplex System |
General
|
Setup Method |
OSD setup menu |
Language |
English, French, Italian, Spanish, German, Russian, Chinese, Japanese |
Power Source and Power Consumption |
24 V AC: 3.6 W, 12 V DC: 410 mA (LED ON) |
Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
Ambient Operating Humidity |
90 % or less (without condensation) |
Dimensions |
ø123 mm x 106 mm (ø4-27/32 inches x 4-3/16 inches) |
Mass (approx.) |
390 g (0.86 lbs.) |
Finish |
White (N5040-b1) |
