Camera
|
Image Sensor |
1/3 type interline transfer CCD |
| Effective Pixels |
976 (H) x 582 (V) |
| Scanning Mode |
2:1 interlace |
| Scanning Area |
4.8 mm (H) x 3.6 mm (V) {3/16 inches(H) x 1/8 inches(V) } |
| Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
| Horizontal Resolution |
650 TV lines (typ.) |
| Minimum Illumination |
Color : 0.15 lx(color mode) B/W: 0.015 lx (black-and-white mode, LED OFF) B/W: 0 lx (black-and-white mode, LED ON |
| Signal-to-Noise Ratio |
52 dB (AGC: OFF |
| White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K |
| Light Control |
ELC |
| BLC |
ON / OFF |
| ABS |
ON / OFF |
| AGC |
ON (LOW, MID, HIGH) / OFF |
| Electronic Shutter |
- |
| Electronic Sensitivity UP |
32x max. AUTO |
| Day Night (IR) |
AUTO1 / AUTO2 / ON / OFF |
| LED |
OFF / AUTO / FIX (available for D&N AUTO2 mode or D&N ON mode |
| Digital Noise Reduction |
high or low |
| Scene File |
2 patterns |
| Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
| Privacy Zone |
ON(1) / ON(2) / OFF |
| Image Stabilizer |
ON / OFF |
| Auto Focus |
None |
| IR LED irradiation distance |
10 m |
| Synchronization |
Internal (INT) |
|
Lens
|
Focal Length |
2.8 mm |
| Zoom Ration |
- |
| Angular Field of View |
H: 101° 30' V: 75° |
| Maximum Aperture Ratio |
F2.0 |
| Focusing Range |
0.5 m ~ ∞ |
|
Input / Output
|
Video Output |
1.0 V [p-p] / PAL composite 75 |
| Controller Interface |
Coaxial Multiplex System |
|
General
|
Setup Method |
OSD setup menu |
| Language |
English, French, Italian, Spanish, German, Russian, Chinese, Japanese |
| Power Source and Power Consumption |
24 V AC: 3.6 W, 12 V DC: 410 mA (LED ON) |
| Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
| Dimensions |
ø123 mm x 106 mm (ø4-27/32 inches x 4-3/16 inches) |
| Mass (approx.) |
330 g (0.73 lbs.) |
| Finish |
White (N5040-b1) |
