System |
Main Processor |
Dual-core embedded processor |
Operating System |
Embedded Linux® |
Language |
English / Thai / Vietnamese |
Video / Audio |
|
IP Camera Input |
16 channels (Only E-Series camera) |
Audio |
1channel Input (RCA), 1channel Output (RCA) |
Display |
Interface |
1 HDMI, 1 VGA, 1 BNC |
Resolution |
1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768 |
Display Split |
1 / 4 / 8 / 9 / 16 |
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
Compression |
H.264 / MJPEG |
Resolution |
3 Mp (2048 × 1536) / 1080p (1920 × 1080) / 720p (1280 × 720) / D1 (704 × 480) / VGA (640 × 480) / CIF (352 × 240) & etc. |
Maximum Bandwidth |
Total 200 Mbps or less |
Bit Rate |
48 - 8192 kbps * Suggested to set bit rate for E-Series camera to 4 Mbps or less |
Record Mode |
Manual, Schedule {Regular (Continuous), VMD, Alarm}, Stop |
Record Interval |
Recording duration : 1 - 120 min (default : 60 min), Pre-record : 1 - 30 sec, Post-record : 10 - 300 sec |
Video Detection & Alarm |
Alarm Action |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Alarm pop-up |
Video Detection |
Video Motion Detection, Camera Blank |
Alarm Input |
16 channel |
Relay Output |
4 channel |
Playback & Backup |
Sync Playback |
1 / 4 / 8 / 16 |
Search Mode |
Time/Date, Alarm, VMD & Exact search (accurate to second), Smart search |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next le, Previous le, Next camera, Previous camera, Full screen, Repeat, Backup selection, Digital zoom |
Backup Mode |
USB Device / Network / eSATA Device |
Network |
Ethernet |
1 RJ45 port (10 / 100 / 1000 Mbps) |
PoE |
16 ports (IEEE802.3at) |
Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP*, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search * Suggested to synchronize to external NTP server |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android™ |
Storage |
Internal HDD |
4 SATA ports, up to 16 TB (External HDD : 1 eSATA port) |
External Interface |
|
USB |
2 ports (1 Rear USB3.0,1 Front USB2.0) |
General |
Safty / EMS Standard |
<Safety> : CE, IEC60950-1 <EMC> : EN55022 Class B, EN55024 |
Power Supply |
AC 100 V to 240 V, 50/60 HZ (For main unit) |
Power Consumption |
NVR : 30 W (without HDD) PoE : Max 25.5 W for single port |
Ambient Operating Temperature/ Humidity |
-10°C to +55°C / 10% to 90%RH / 86~106 kpa |
Dimension (W × D × H) |
440mm (W) × 410mm (D) × 70mm (H) |
Weight |
6 kg (without HDD) |
