| Server |
| Image compression |
: |
*1 H.264, MPEG-4, Motion JPEG for moving image display |
| Video resolution |
: |
H.264: 640 x 480, 320 x 240 MPEG-4: 640 x 480, 320 x 240, 192 x 144 JPEG: 640 x 480, 320 x 240, 192 x 144 |
| Frame rate |
: |
*2 Max. 30 frames/sec. (640 x 480, 320 x 240, 192 x144) |
| Security |
: |
User ID / Password/SSL |
| Supported protocols |
: |
IPv4 / IPv6 Dual-Stack IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnPTM, Auto IP, SMTP Authentication, RTP, RTSP, RTCP IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP, RTCP |
| User access limit |
: |
2/H.264, 4/MPEG-4, 10/MotionJPEG |
| Buffered images |
: |
Approx. 1160 images (320 x 240) -Standard image quality -with time display |
| Image transfer method |
: |
SMTP*3, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Timer, Sensor, Alarm 1, Alarm 2, Motion Detection, Sound Detection |
Network Camera |
| Viewing angle |
: |
58° horizontal 45° Vertical |
| Sensor type |
: |
1/4 inch CMOS Progressive Scan, approx. 320,000 pixel |
| Lens focal point |
: |
Fixed (focal range: 0.3 m to Infinity) |
| Lens brightness |
: |
F2.8 |
| Required light intensity |
: |
5-10,000 lx (3-10,000 lx when in Colour Night View mode) |
Audio |
Not Available
Wireless |
| Standards |
: |
IEEE 802.11b, 802.11b/g, 802.11g exclusive |
| Antenna |
: |
BL-C230CE/BL-C230E:2.412-2.472 GHz |
| Number of channel |
: |
BL-C230CE/BL-C230E:1-13 |
| Security |
: |
SSID, WEP (64/128/152 bit), WPA-PSK (TKIP), WPA2-PSK (AES) |
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
Input: 2, output: 1 |
General |
| Operating temperature |
: |
Operation: +0 °C (+32 °F) to +40 °C (+104 °F) Storage: +0 °C (+32 °F) to +50 °C (+122 °F) |
| Operating humidity |
: |
Operation: 20 %-80 % (no condensation) Storage: 20 %-90 % (no condensation) |
| Dimensions (H x W x D) |
: |
74 mm x 74 mm x 101 mm (2 15/16 inches x 2 15/16 inches x 4 inches) |
| Weight (only the unit) |
: |
260 g (0.57 lb) |
| Power supply (CE) |
: |
AC adaptor (order no. PQLV206CEY) Input 100-240 V AC, 50/60 Hz Output 9 V DC, 750 mA |
| Consumption |
: |
About 4.0 W (7.7 W during pan/tilt scan) |
