| Server |
| Image compression |
: |
*1 H.264, MPEG-4, Motion JPEG for moving image display |
| Video resolution |
: |
H.264: 640 x 480, 320 x 240 MPEG-4: 640 x 480, 320 x 240, 192 x 144 JPEG: 640 x 480, 320 x 240, 192 x 144 |
| Frame rate |
: |
*2 Max. 30 frames/sec. (640 x 480, 320 x 240, 192 x144) |
| Security |
: |
User ID / Password/SSL |
| Supported protocols |
: |
IPv4 / IPv6 Dual-Stack IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnPTM, Auto IP, SMTP Authentication, RTP, RTSP, RTCP IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP, RTCP |
| User access limit |
: |
2/H.264, 4/MPEG-4, 10/MotionJPEG |
| Buffered images |
: |
Approx. 1160 images (320 x 240) -Standard image quality -with time display |
| Image transfer method |
: |
SMTP*3, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Timer, Sensor, Alarm 1, Alarm 2, Motion Detection, Sound Detection |
Network Camera |
| Viewing angle |
: |
58° horizontal 45° Vertical |
| Sensor type |
: |
1/4 inch CMOS Progressive Scan, approx. 320,000 pixel |
| Lens focal point |
: |
Fixed (focal range: 0.3 m to ∞) |
| Lens brightness |
: |
F2.8 |
| Required light intensity |
: |
5-10,000 lx (3-10,000 lx when in Colour Night View mode) |
Audio |
Not Available
Wireless |
Not Available
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
Input (2) |
General |
| Operating temperature |
: |
0°C to + 40°C (+32°F to +104°F) |
| Operating humidity |
: |
20 % to 80% |
| Dimensions (H x W x D) |
: |
74mm x 74mm x 91mm (2 15/16 inches x 2 15/16 inches x 3 9/16 inches) |
| Weight (only the unit) |
: |
230 g (1.09lb.) |
| Power supply (CE) |
: |
AC adaptor : input 100 - 240 V AC, Output 9V DC 750mA |
| Consumption |
: |
AC adaptor: 5.4 W |
