| Server |
| Image compression |
: |
JPEG (Motion JPEG), MPEG-4 |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 192 x 144 |
| Image quality |
: |
JPEG (favor clarity, standard, favor motion), MPEG4 |
| Frame rate |
: |
Max. 30 frames/sec. (640 x 480, 320 x 240, 192 x144) |
| Security |
: |
User ID/Password |
| Supported protocols |
: |
IPv4/IPv6 Dual-Stack IPv4: TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, NTP, UPnPTM, SMTP Authentication, RTP, RTSP, RTCP IPv6: TCP, UDP, IP, HTTP, FTP, SMTP, DNS, ICMPv6, POP3, NDP, NTP, RTP, RTSP, RTCP |
| User access limit |
: |
Max. 30 simultaneous accesses |
| Buffered images |
: |
Approx. 350 images (320 x 240) •standard image quality •with time display •without using SD Memory Card |
| Image transfer method |
: |
SMTP, FTP, HTTP |
| Image buffer/transfer triggers |
: |
Alarm, timer or motion detection |
Network Camera |
| Zoom |
: |
42x zoom (21x optical, 2x digital) |
| Viewing angle |
: |
Horizontal--tele: 2.6° (optical) /1.3° (digital), wide: 51° | Vertical----tele: 1.9° (optical) /0.9° (digital), wide: 38° |
| Pan (horizontal direction) |
: |
-175° up to +175° |
| Tilt (vertical direction) |
: |
-120° up to 0° (on a table), 0° up to +90° (on a ceiling) |
| Revolving speed |
: |
Pan: Max. 300°/sec, Tilt: Max. 200°/sec |
| Sensor type |
: |
1/4 inch CCD sensor, approx. 320,000 pixels |
| Lens focal point |
: |
Auto/Manual (40 steps) |
| Lens brightness |
: |
F1.6 (Wide) - 3.6 (Tele) |
| Required light intensity |
: |
2 to 100,000 lux (in color night view mode: 0.09 to 100,000 lux) |
Audio |
| Audio communication |
: |
2-Way half duplex |
| Audio compression |
: |
ADPCM 32 kbps |
| Audio bandwidth |
: |
300 Hz - 3.4 kHz |
| Audio input |
: |
External microphone input terminal |
| Audio output |
: |
Audio line output terminal for external speaker |
Wireless |
| Standards |
: |
— |
| Antenna |
: |
— |
| Number of channel |
: |
— |
| Transmission speed |
: |
— |
| Security |
: |
— |
Terminal |
| Network interface |
: |
Ethernet (10Base-T/100Base-TX) |
| External I/O connector |
: |
Input: 2, output: 1 |
| Video output |
: |
Analog composite (NTSC/PAL) |
| Audio output |
: |
3.5 mm stereo mini jack (output is mono) |
| External Microphone Input |
: |
3.5 mm mini jack |
| SD Memory Card slot |
: |
Full size (operation guaranteed for 2GB, 1GB, 512MB, 256MB, 128MB and 64MB SD Memory Cards) |
General |
| Operating temperature |
: |
0°C to +40°C (+32°F to +104°F) |
| Operating humidity |
: |
20% to 80% (No Condensation) |
| Dimensions (H x W x D) |
: |
140 x 123 x 123 mm (5 1/2 x 4 13/16 x 4 13/16 inches) |
| Weight (only the unit) |
: |
650g (1.43lb.) |
| Power supply (E) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet | AC adaptor: input 100 - 240 V AC, output 12 V DC |
| Power supply (CE) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet | AC adaptor: input 100 - 240 V AC, output 12 V DC |
| Power supply(US) |
: |
PoE: 48 V, IEEEE 802.3af-compliant Power over Ethernet | AC adaptor: input 120 V AC, output 12 V DC |
| Consumption |
: |
PoE : 9W | AC adaptor : 10.5W |
| |
| Other Detail |
: |
System Requirements for PC:
1. Operating System:
For IPv4 Connection
Microsoft® Windows Vista®
Microsoft® Windows® XP
Microsoft® Windows® 2000
For IPv6 Connection
Microsoft® Windows Vista®
Microsoft® Windows® XP Service Pack 1 or later
2. CPU:
2.0 GHz Celeron® or faster
3. Display:
1024 x 768 resolution or higher
4. Protocol:
For IPv4 Connection
TCP/IP protocol (HTTP, TCP, UDP, IP, DNS, ARP,ICMP)
For IPv6 Connection
TCP/IP protocol (HTTP, TCP, UDP, IP, DNS, ICMPv6, NDP)
5. Interface:
10/100 Mbps network card
6. Web Browser:
Internet Explorer® 6.0 or later (not included)
7. Audio:
PC speaker or headphones (required to use the Listen feature)
External speaker for camera (required to use the Talk feature)
8. Additional software (for viewing buffered MPEG-4 images):
For Windows Vista®
Windows Media® Player 11 or later
For Windows® XP
Windows Media® Player 9 or later
For Windows® 2000
Windows Media® Player 9 |
