| Server |
| Image compression |
: |
JPEG/3 Levels |
| Video resolution |
: |
640 x 480, 320 x 240 (default), 160 x 120 |
| Frame rate |
: |
Max. 15 frames/second (320 x 240, 160 x 120). Max. 7.5 frames/second (640 x 480). |
| Security |
: |
ID/Password |
| Supported protocols |
: |
TCP, UDP, IP, HTTP, FTP, SMTP, POP3, DHCP,DNS,DDNS,ARP,ICMP,NTP |
| User access limit |
: |
Max. 10 simultaneous users |
| Buffered images |
: |
About 80 frames (320 x 240) with time information |
| Image transfer method |
: |
SMTP, FTP |
| Image buffer/transfer triggers |
: |
Alarm and Timer |
Network Camera |
| Zoom |
: |
100% or 150% |
| Viewing angle |
: |
Right and left 45° (totally 165° by Pan Operation); Up and down 33° (totally 78° by Tilt Operation) |
| Pan (horizontal direction) |
: |
- 60° to + 60° |
| Tilt (vertical direction) |
: |
0° to - 45° |
| Sensor type |
: |
1/3 inch CMOS. 320,000 pixels (Effective Pixels) |
| Lens focal point |
: |
Fixed 1 m-Infinity |
| Lens brightness |
: |
F1.8 |
| Required light intensity |
: |
10-10,000 lx |
Audio |
Not Available
Wireless |
Not Available
Terminal |
Not Available
General |
| Operating temperature |
: |
+5°C to +40°C |
| Operating humidity |
: |
20% to 80% (No Condensation) |
| Dimensions (H x W x D) |
: |
116 mm (4.57") x 115 mm (4.57") x 72 mm (2.83") |
| Weight (only the unit) |
: |
350g (0.77 lb.) |
| Power supply (E) |
: |
AC adapter code length: 5m. Input 100-240 V AC, 50/60 Hz Output 9 V DC |
| Power supply (CE) |
: |
AC adapter code length: 5m. Input 100-240 V AC, 50/60 Hz Output 9 V DC |
| Power supply(US) |
: |
AC adapter code length: 5m. Input 120 V AC, 60 Hz Output 9 V DC |
| Consumption |
: |
Standby: 6 W, MAX.8 W |
