Hikvision DS-2DE4220IW-DE

Image Sensor:

1/2.8" Progressive Scan CMOS

Effective Pixels:

1920(H)x1080(V)

Signal System:

PAL/NTSC

Minimum Illumination:

F1.6, AGC On: Color: 0.05 lux, B/W : 0.01 lux, 0 lux with IR

White Balance:

Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp

AGC:

Auto/Manual

BLC:

ON/OFF

HLC:

Support

WDR:

Support

Shutter Time:

1-1/10,000s

Day& Night:

ICR

Digital Zoom:

16X

Privacy Masking:

8 privacy masks programmable

Auto Focus:

Auto / Semi-automatic / Manual

Focal Length:

4.7-94.0mm, 20x

Zoom Speed:

Approx.3s(Optical Wide~Tele)

Angle of View:

58.3-3.2 degree (Wide~Tele)

Aperture Range:

F1.6~F3.5

Minimum Working Distance:

10~1,000mm(Wide~Tele)

Range:

360°endless

Speed:

Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s

Tilt Range:

-15°-90° (Auto Flip )

Tilt Speed:

Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s

Proportional Zoom:

Rotation speed can be adjusted automatically according to zoom multiples

Number of Preset:

300

Patrol:

8 patrols, up to 32 presets per patrol

Power loss recovery:

Support

Park Action:

Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan

PTZ Position Display:

ON/OFF

IR irradiation distance:

100m

IR irradiation angle:

Adjustable by zoom

Ethernet:

10Base -T, /100Base-TX, RJ45 Connector

Max.Image Resolution:

1920×1080

Frame Rate:

50Hz:25fps(1920×1080), 25fps (1280×720),
60Hz:30fps(1920×1080), 30fps (1280×720)

Main Stream:

50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)

Sub Stream:

50Hz:25fps(704×576), 25fps(640×576), 25fps(320×288)
60Hz:30fps(704×480), 30fps(640×480), 30fps(320×240)

Third Stream:

50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)
60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640x480,352×288)

Image Compression:

H.264 / MJPEG

ROI encoding:

Support 4 areas with adjustable levels

Protocols:

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

No. of Simultaneous Users:

Up to 20 users

Dual Stream:

Support

Mini SD Card:

Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording

User/Host Level:

Up to 32 users,3 Levels: Administrator, Operator and User

Security Measures:

User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering

EZVIZ:

Support

Date & Time Display:

Time: Week: Date, 6 formats on the Client

Camera Control:

Pan/Tilt, Zoom, Focus, Click Centering, Zoom by mouse for dragging, Iris, Preset calling and programming, auto mode

Client:

Support iVMS-4200

Web Browser:

IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +

Menu Language:

English

Power Supply:

12V DC or PoE((802.3at, class4)

Power Consumption:

Max. 20W

Working Temp/Humidity:

-30°C ~ 65°C (-22°F ~ 149°F)

Protection Level:

IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection

Mounting:

Various mounting modes optional

Dimensions:

Φ164.5(mm)×295(mm)

Weight (approx.):

2kg (4.41lbs)

Mount Option:

Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ
