| Camera Module |
| Image Sensor |
1/2.8" progressive scan CMOS |
| Min. Illumination |
ƒ/1.6, AGC on, color: 0.05 lux, B/W: 0.01 lux |
| Max. Image Resolution |
2048 × 1536 |
| Focal Length |
2.8 mm to 12 mm, 4x |
| Digital Zoom |
16x |
| Angle of View |
105° to 33.5° (wide to tele) |
| Aperture Range |
ƒ/1.6 to ƒ/2.7 |
| Focus Mode |
Auto/semiautomatic/manual |
| WDR |
DWDR |
| S / N Ratio |
≥52 dB |
| Shutter Time |
1/1 to 1/10,000 s |
| AGC |
Auto/manual |
| White Balance |
Auto/manual/ATW/indoor/outdoor/daylight lamp/sodium lamp |
| Day & Night |
IR cut filter |
| Privacy Mask |
8 privacy masks programmable |
| Enhancement |
3D DNR, HLC/BLC |
| Pan and Tilt |
| Range |
Pan: 0° to 350°; tilt: 5° to 90° |
| Speed |
Pan: 0.1° to 60°/sec (manual), 30°/s (preset)
Tilt: 0.1° to 50°/sec (manual), 25°/s (preset) |
| Number of Preset |
300 |
| Patrol |
8 patrols, up to 32 presets per patrol |
| Park Action |
Preset/patrol |
| Scheduled Task |
Preset/reboot/patrol/self test/aux output |
| Smart Features |
| Smart detection |
Intrusion detection, line crossing detection, audio exception detection, motion detection |
| ROI encoding |
Supports 4 areas with adjustable levels |
| Alarm |
| Alarm I/O |
1/1 |
| Alarm Trigger |
Intrusion detection, line crossing detection, motion detection, audio exception detection, dynamic analysis, tampering alarm, network disconnect, IP address conflict, storage exception |
| Alarm Action |
Preset, recording, relay output, upload center, upload FTP, e-mail linkage |
| Input/Output |
| Audio Input |
1 audio input (mic/line in), 2 to 2.4V[p-p]; output impedance: 1K Ω, ±10% |
| Audio Output |
1 output, line level, impedance: 600 Ω |
| Network |
| Protocols |
10Base-T/100Base-TX, RJ-45 connector |
| Simultaneous Live View |
Up to 20 users |
| Mini SD Memory Card |
Supports up to 128 GB microSD/SDHC/SDXC card and edge recording |
| User/Host Level |
Up to 32 users,3 levels: administrator, operator, and user |
| Security Measures |
User authentication (ID and PW); host authentication (MAC address); IP address filtering |
| System Integration |
| Application programming |
Open-ended API, supports ONVIF, PSIA, CGI, and Genetec |
| Web Browser |
IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+ |
| Power |
POE, 12 VDC, maximum 8 W |
| Working Temperature |
-30° C to 65° C (-22° F to 149° F) |
| Humidity |
90% or less |
| Certification |
FCC, CE, UL, RoHS, IEC/EN 61000, IEC/EN 55022, IEC/EN 55024, IEC/ EN60950-1 |
| Dimensions |
Φ140.7 mm × 107.2 mm (5.54" x 4.22") |
| Weight (approx.) |
950 g (33.5 oz)
|
