Brand: CP Plus

CP Plus CP-UNC-DP10L2C

Rp 4.400.000

tidak termasuk pengiriman

• 1/3” 1.3 Megapixel CMOS image sensor
• H.264 & MJPEG dual-stream encoding
• Max 15fps@1.3M (1280x960) & 25/30fps@720P (1280x720)
• Day / Night (ICR), 2DNR, AWB, AGC, BLC
• Max. IR distance : 20m
• 3.6mm Lens (2.8mm / 6mm optional)
• Support PoE, IP66
• Mobile Software : CMOB
• CMS Software : IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 1.3 Megapixel CMOS
Minimum Illumination	0.1LUX/F1.2
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	3.6mm (2.8mm/6mm/8mm optional)
Back Light Comp.	BLC
Video Compression	H.264/MJPEG/JPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)
Frame Rate	720P@1~25fps, 1.3MP@1~15fps
User Account	10 users
Privacy Masking	Up to 4 areas
Video Streaming	Main Stream 1.3M(1~15fps)/720P(1 ~ 25/30fps), Sub Stream D1/CIF(1 ~ 25/30fps)
Dimension	φ114 x 86mm
Interface	RJ-45(10/100Base-T)
Protocol	IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE
Power Consumption	Max. 4W
Weight	0.288kg
S/N Ratio	More than 50 dB
ICR	Auto(ICR) / Color / B/W
Snapshot	Fastest 1fps JPEG capture
Event Notification	HTTP, FTP, SMTP
IR	Max. IR Distance : 20m
Weatherproof Standard	IP66

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 1.3 Megapixel CMOS
Minimum Illumination	0.1LUX/F1.2
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	3.6mm (2.8mm/6mm/8mm optional)
Back Light Comp.	BLC
Video Compression	H.264/MJPEG/JPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)
Frame Rate	720P@1~25fps, 1.3MP@1~15fps
User Account	10 users
Privacy Masking	Up to 4 areas
Video Streaming	Main Stream 1.3M(1~15fps)/720P(1 ~ 25/30fps), Sub Stream D1/CIF(1 ~ 25/30fps)
Dimension	φ114 x 86mm
Interface	RJ-45(10/100Base-T)
Protocol	IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+60°C, 10%~90%
Power Source	DC12V, PoE
Power Consumption	Max. 4W
Weight	0.288kg
S/N Ratio	More than 50 dB
ICR	Auto(ICR) / Color / B/W
Snapshot	Fastest 1fps JPEG capture
Event Notification	HTTP, FTP, SMTP
IR	Max. IR Distance : 20m
Weatherproof Standard	IP66
