Produk sebelumnyaCP Plus CP-UNC-VY30FL2C

Brand: CP Plus

CP Plus CP-UNC-DP10

Rp 3.700.000

tidak termasuk pengiriman

1/3” 1.3 Megapixel Aptina CMOS image sensor
H.264 & MJPEG dual-stream encoding
Max 15fps@1.3M(1280×960)&25/30fps@720P(1280×720)
Day/Night, 2DNR, AWB, AGC, BLC 3.6mm fixed lens (2.8mm,6mm,8mm optional) Mobile Software: CMOB
CMS Software: IPSS

Qty:

Overview
Contact Us

Specifications
Image Sensor	1/3” 1.3 Megapixel CMOS
Minimum Illumination	0.1LUX/F1.4
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	3.6mm (2.8mm/6mm/8mm optional)
Back Light Comp.	BLC
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)
Frame Rate	1~25fps
User Account	10 users
Privacy Masking	Up to 4 areas
Video Streaming	Main Stream 1.3M(1~15fps)/720P(1 ~ 25/30fps), Sub Stream D1/CIF(1 ~ 25/30fps)
Dimension	Φ110×54mm
Interface	RJ-45(10/100Base-T)
Protocol	IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+50°C, 10%~90%
Power Source	DC12V, PoE
Power Consumption	Max.1.5W
Weight	0.25kg

Namamu *

Email Anda *

Pertanyaan *

Specifications
Image Sensor	1/3” 1.3 Megapixel CMOS
Minimum Illumination	0.1LUX/F1.4
Shutter Speed	Auto/Manual, 1/3~1/10000s
White Balance	Auto
AGC control	Auto/Manual
Lens	3.6mm (2.8mm/6mm/8mm optional)
Back Light Comp.	BLC
Video Compression	H.264/MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480)
Frame Rate	1~25fps
User Account	10 users
Privacy Masking	Up to 4 areas
Video Streaming	Main Stream 1.3M(1~15fps)/720P(1 ~ 25/30fps), Sub Stream D1/CIF(1 ~ 25/30fps)
Dimension	Φ110×54mm
Interface	RJ-45(10/100Base-T)
Protocol	IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,Bonjour, ONVIF Ver. 2.0
Smart Phone	iPhone, iPad, Android, Windows Phone
Operating Temperature	-10°C~+50°C, 10%~90%
Power Source	DC12V, PoE
Power Consumption	Max.1.5W
Weight	0.25kg
