Image Sensor
|
Visual camera: 1/3’’ progressive scan CMOS 2 megapixel Thermal camera: Uncooled micro bolometer 384x288 pixels |
Lens
|
Visual camera: f=5.1–51 mm, F1.8–2.1, Autofocus, Automatic day/night Horizontal angle of view: 48.1°–5.1° M37x0.75 mounting thread for optional lens adaptor |
Detection range
|
See tables above |
Min.Illumination
|
Visual camera: Color: 2 lux at 30 IRE, F1.8 B/W: 0.2 lux at 30 IRE, F1.8 |
Sensitivity
|
Thermal camera: NETD < 100 mK |
Shutter Time
|
Visual camera: 1/10000 s to 1/2 s |
Pan/ Tilt/ Zoom
|
Pan: 360° endless, 0.1°–20°/s Tilt: 45° to -20°, 0.1°–20°/s Visual camera: 10x optical and 12x digital, total 120x Protocol: Macro Preset accuracy: 0.02° |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Motion JPEG |
Video Resolution
|
Visual camera with HDTV 1080i 1920x1080, HDTV 720p 1280x720; and Thermal camera with 384x288 sensor, image can be scaled up to 768x576 and to standard VGA resolution |
Video Frame Rate
|
Visual camera: 30/25 fps in all resolutions and video compression Thermal camera: Up to 30 fps within EU, Norway, Switzerland, Canada, USA, Japan, Australia, New Zealand Up to 8.3 fps in other countries a |
Video Streaming
|
Visual camera: Multiple, individually configurable streams in H.264 and Motion JPEG Thermal camera: At least 1 stream in H.264 and Motion JPEG: Simultaneous, individually configured streams in max. resolution at 30 fps Controllable frame rate and bandwidth, VBR/CBR H.264 |
Image settings
|
Visual camera: Compression, Brightness, Sharpness, White balance, Exposure control, Backlight compensation, Text and image overlay, Mirroring of images, Rotation Thermal camera: Compression, Brightness, Exposure control, Text and image overlay, Mirroring of images, Rotation, Multiple palettes |
Security
|
Password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, Digest authentication, User access log |
Protocol Support
|
IPv4/v6, HTTP, HTTPSb , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com Interface specifications available at www.axis.com |
Intelligent Video
|
Video motion detection, Active tampering alarm AXIS Camera Application Platform enabling installation of additional applications Visual camera: Gatekeeper |
Trigger Events
|
Intelligent video, External output |
Event actions
|
File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video recording to edge storage Pre- and post-alarm video buffering External output activation |
Data streaming
|
Event data |
Casing
|
Aluminum casing, sunshield ABS PMMA, IP66-rated Color: RAL 9002 |
Memory
|
Visual camera: 256 MB RAM, 128 MB Flash Thermal camera: 128 MB RAM, 128 MB Flash |
Power
|
24 V AC 50/60 Hz, 200 W provided by power supply (sold separately) 230/120 V AC 50/60 Hz with built-in day/night sensor |
Edge Storage
|
SD/SDHC/SDXC slot supporting memory cards up to 64 GB (card not included) Support for recording to network share (network-attached storage or file server) |
Operating Conditions
|
-30 °C to 45 °C (-22 °F to 113 °F) Humidity 10–100% RH (condensing) |
Approvals
|
EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, C-tick AS/NZS CISPR 22 Class A, EN 60950-1, EN 60950-22, IEC/EN 60529 IP66 Power supply (sold separately): EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, C-tick AS/NZS CISPR 22 Class A, EN 60950-1, EN 60950-22, IEC/EN 60529 IP66 |
Weight
|
28.5 kg (63 lb) (IR LED excluded) |
Included accessories
|
Installation Guide, Installation and Management Software CD, Windows decoder 1-user license |
Video Management Software
|
AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software |
Required Hardware
|
AXIS Q87-E Power Supply 230 V AC or AXIS Q87-E Power Supply 120 V AC AXIS Wall Bracket K or AXIS Column Bracket K |
