Brand: Axis

Axis Q6044-S

Marine-grade stainless steel.
Casing for pressurized nitrogen.
HDTV 720p and 30x optical zoom.
SFP slots for fiber, RJ45 connections.
I/O for alarm in/out.

Qty:

Overview
Specifications
Contact Us

AXIS Q6044-S PTZ DOME NETWORK CAMERA

AXIS Q6044-S merupakan kamera pengawas dengan casing stainless steel berkecapatan tinggi. Kamera pengawas beresolusi 720p dengan 30x optical zoom dan autofocus. Kamera dengan cakupan bidang wilayah pengawasan 360º sangat tepat untuk mengawasi lokasi yang luas. AXIS Q6044-S adalah kamera yang menggunakan tekanan nitrogen yang dapat digunakan untuk mengawasi pertambangan, kelautan, lingkungan gas dan minyak serta untuk mengawasi kegiatan pada manufaktur.

AXIS Q6044-S terbuat dari stainless steel (SAE 316L / V4A) dan nilon dome dengan penutup yang jelas, kamera ini memiliki resistensi yang tinggi terhadap efek korosif dari air laut dan bahan kimia pembersih. Kamera ini dapat beroperasi pada suhu -30° C hingga 50° C (-22° F sampai 122° F), dengan standar MIL-STD-810G 509,5, IP6K9K, IP66, IP67 dan NEMA 4X memastikan perlindungan terhadap kabut garam, tekanan tinggi, debu, hujan, salju dan es. AXIS Q6044-S juga dirancang untuk diisi dengan nitrogen-berwarna, non-reaktif dan tidak mudah terbakar karena nitrogen merupakan gas yang membentuk 78% dari atmosfer bumi. Nitrogen dalam lingkungan yang disegel memberikan keunggulan seperti mencegah kondensasi internal.

FITUR AXIS Q6044-S

Sensor gambar 1/3” Progressive scan CCD.
Lensa 4.4-132 mm, F1.4-4.6 Horizontal angle of view 62.9°-2.2° Vertical angle of view 37°-1.2° Autofocus.
Minimal iluminasi warna: 0.2 lux at 30 IRE F1.4, hitam putih: 0.04 lux at 30 IRE F1.4.
Mampu beroperasi dengan sangat baik pada suhu -30 °C hingga 50 °C (-22 °F to 122 °F).
Fungsi Edge Storage untuk penyimpan kartu SD/SDHC/SDXC.

Jual kamera CCTV seperti IP Kamera, Dome Kamera, Analog Kamera dan berbagai macam jenis CCTV lainnya dari brand AXIS. JakartaCCTV distributor kamera CCTV menjual berbagai macam CCTV berkualitas dari berbagai brand ternama dengan harga murah di Jakarta. Tersedia pula jasa pemasangan CCTV yang ditangani langsung oleh teknisi - teknisi yang handal dan berpengalaman pada bidang pemasangan CCTV. Jika Anda ingin membeli Infrared camera dengan harga infrared camera murah Anda dapat menghubungi JakartaCCTV, JakartaCCTV jual ir camera di Jakarta.

Spesifikasi produk

Image Sensor	1/3” Progressive scan CCD
Lens	4.4-132 mm, F1.4-4.6 Horizontal angle of view 62.9°-2.2° Vertical angle of view 37°-1.2° Autofocus
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	Color: 0.2 lux at 30 IRE F1.4 B/W: 0.04 lux at 30 IRE F1.4
Shutter Time	1/10000 s to 1/4 s
Pan/ Tilt/ Zoom	Pan: 360° endless, 0.05° - 450°/s Tilt: 220°, 0.05°-450°/s 30x optical zoom and 12x digital zoom, total 360x zoom E-flip, 256 preset positions, Tour recording, Guard tour, Control queue, On-screen directional indicator, Set new pan 0°, Adjustable zoom speed
Video Compression	H.264 (MPEG-4 Part 10/AVC) Baseline and Main Profiles Motion JPEG
Video Resolution	HDTV 720p 1280x720 to 320x180
Video Framerate	Up to 30/25 fps (60/50 Hz) in all resolutions
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/MBR H.264
Image settings	Wide Dynamic Range (WDR), manual shutter time, compression, color, brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, rotation: 0°, 180°, text and image overlay, 32 individual 3D privacy masks, image freeze on PTZ, electronic image stabilization, automatic defog
Security	Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management
Protocol Support	IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org
Analytics	Video motion detection, Autotracking, Active Gatekeeper Support for AXIS Camera Application Platform enabling installation of AXIS Cross-line detection and third-party applications, see www.axis.com/acap
Trigger Events	Analytics, Shock detection, Fan, Temperature, Manual trigger, PTZ moving, PTZ preset, Edge storage events Heater
Event actions	File upload: FTP, SFTP, HTTP, HTTPS network share and email Notification: email, HTTP, HTTPS and TCP Day/night mode, Guard tour, Video recording to edge storage, Pre- and post-alarm video buffering, PTZ preset, Overlay text, Send SNMP trap
Data streaming	Event data
Built-in installation aids	Pixel counter
Casing	IP6K9K-, IP66-, IP67-, NEMA 4X-, NEMA 6P- and IK10-ratedb stainless steel casing (V4A, SAE 316L/UNS S31603/EN 1.4432), Nylon clear dome
Memory	512 MB RAM, 128 MB Flash Battery backed-up real-time clock
Power	12.0-13.2 V DC, min. 75 W
Connectors	RJ45 10BASE-T/100BASE-TX, IP66-rated multi-connector for DC power, input and output, including 7 m (23 ft) cable
Edge Storage	Support for SD/SDHC/SDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com
Operating Conditions	-30 °C to 50 °C (-22 °F to 122 °F) Humidity 10-100% RH (condensing)
Storage Temperature	-40 °C to 65 °C (-40 °F to 149 °F)
Approvals	EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR 22 Class A KCC KN22 Class A, KN24, IEC/EN/UL 60950-1 EN 50121-4, IEC 62236-4, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, NEMA 250 Type 4X IEC/EN/UL 60950-22, IEC 60068-2-30, IEC 60068-2-60, IEC 60068-2-78 IEC/EN 60529 IP66, IP67, IP6K9K, NEMA 250 Type 6P, MIL-STD 810G 509.5
Weight	5.7 kg (12.6 lb)
Dimension	Without sunshield: Ø224 x 256 mm (Ø8.8 x 10.1 in), With sunshield: Ø250 x 256 mm (Ø9.8 x 10.1 in)
Included accessories	AXIS T8605 Media Converter Switch, 7 m (23 ft) IP66-rated multi-connector cable Installation Guide, Windows decoder 1-user license
Optional accessories	Power Supply, SFP modules, Wall bracket, AXIS T91C67 Pole Bracket, AXIS T91C61 Wall Mount, AXIS T94S01D Pendant kit (1 1/2" NPT male Thread Adapter), Smoked dome cover, Stainless steel sunshield AXIS T90 Illuminators, AXIS T8310 Video Surveillance Control Board, Installation Display, Multi-user decoder license pack
Video Management Software	AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software
Language	German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese

Namamu *

Email Anda *

Pertanyaan *

AXIS Q6044-S PTZ DOME NETWORK CAMERA

FITUR AXIS Q6044-S

Sensor gambar 1/3” Progressive scan CCD.
Lensa 4.4-132 mm, F1.4-4.6 Horizontal angle of view 62.9°-2.2° Vertical angle of view 37°-1.2° Autofocus.
Minimal iluminasi warna: 0.2 lux at 30 IRE F1.4, hitam putih: 0.04 lux at 30 IRE F1.4.
Mampu beroperasi dengan sangat baik pada suhu -30 °C hingga 50 °C (-22 °F to 122 °F).
Fungsi Edge Storage untuk penyimpan kartu SD/SDHC/SDXC.

Spesifikasi produk

Image Sensor	1/3” Progressive scan CCD
Lens	4.4-132 mm, F1.4-4.6 Horizontal angle of view 62.9°-2.2° Vertical angle of view 37°-1.2° Autofocus
Day/Night	Automatically removable infrared-cut filter
Min.Illumination	Color: 0.2 lux at 30 IRE F1.4 B/W: 0.04 lux at 30 IRE F1.4
Shutter Time	1/10000 s to 1/4 s
Pan/ Tilt/ Zoom	Pan: 360° endless, 0.05° - 450°/s Tilt: 220°, 0.05°-450°/s 30x optical zoom and 12x digital zoom, total 360x zoom E-flip, 256 preset positions, Tour recording, Guard tour, Control queue, On-screen directional indicator, Set new pan 0°, Adjustable zoom speed
Video Compression	H.264 (MPEG-4 Part 10/AVC) Baseline and Main Profiles Motion JPEG
Video Resolution	HDTV 720p 1280x720 to 320x180
Video Framerate	Up to 30/25 fps (60/50 Hz) in all resolutions
Video Streaming	Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/MBR H.264
Image settings	Wide Dynamic Range (WDR), manual shutter time, compression, color, brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, rotation: 0°, 180°, text and image overlay, 32 individual 3D privacy masks, image freeze on PTZ, electronic image stabilization, automatic defog
Security	Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management
Protocol Support	IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org
Analytics	Video motion detection, Autotracking, Active Gatekeeper Support for AXIS Camera Application Platform enabling installation of AXIS Cross-line detection and third-party applications, see www.axis.com/acap
Trigger Events	Analytics, Shock detection, Fan, Temperature, Manual trigger, PTZ moving, PTZ preset, Edge storage events Heater
Event actions	File upload: FTP, SFTP, HTTP, HTTPS network share and email Notification: email, HTTP, HTTPS and TCP Day/night mode, Guard tour, Video recording to edge storage, Pre- and post-alarm video buffering, PTZ preset, Overlay text, Send SNMP trap
Data streaming	Event data
Built-in installation aids	Pixel counter
Casing	IP6K9K-, IP66-, IP67-, NEMA 4X-, NEMA 6P- and IK10-ratedb stainless steel casing (V4A, SAE 316L/UNS S31603/EN 1.4432), Nylon clear dome
Memory	512 MB RAM, 128 MB Flash Battery backed-up real-time clock
Power	12.0-13.2 V DC, min. 75 W
Connectors	RJ45 10BASE-T/100BASE-TX, IP66-rated multi-connector for DC power, input and output, including 7 m (23 ft) cable
Edge Storage	Support for SD/SDHC/SDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com
Operating Conditions	-30 °C to 50 °C (-22 °F to 122 °F) Humidity 10-100% RH (condensing)
Storage Temperature	-40 °C to 65 °C (-40 °F to 149 °F)
Approvals	EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR 22 Class A KCC KN22 Class A, KN24, IEC/EN/UL 60950-1 EN 50121-4, IEC 62236-4, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, NEMA 250 Type 4X IEC/EN/UL 60950-22, IEC 60068-2-30, IEC 60068-2-60, IEC 60068-2-78 IEC/EN 60529 IP66, IP67, IP6K9K, NEMA 250 Type 6P, MIL-STD 810G 509.5
Weight	5.7 kg (12.6 lb)
Dimension	Without sunshield: Ø224 x 256 mm (Ø8.8 x 10.1 in), With sunshield: Ø250 x 256 mm (Ø9.8 x 10.1 in)
Included accessories	AXIS T8605 Media Converter Switch, 7 m (23 ft) IP66-rated multi-connector cable Installation Guide, Windows decoder 1-user license
Optional accessories	Power Supply, SFP modules, Wall bracket, AXIS T91C67 Pole Bracket, AXIS T91C61 Wall Mount, AXIS T94S01D Pendant kit (1 1/2" NPT male Thread Adapter), Smoked dome cover, Stainless steel sunshield AXIS T90 Illuminators, AXIS T8310 Video Surveillance Control Board, Installation Display, Multi-user decoder license pack
Video Management Software	AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software
Language	German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese
