Image Sensor
|
1/3” Progressive scan CCD |
Lens
|
4.4-132 mm, F1.4-4.6 Horizontal angle of view 62.9°-2.2° Vertical angle of view 37°-1.2° Autofocus |
Day/Night
|
Automatically removable infrared-cut filter |
Min.Illumination
|
Color: 0.2 lux at 30 IRE F1.4 B/W: 0.04 lux at 30 IRE F1.4 |
Shutter Time
|
1/10000 s to 1/4 s |
Pan/ Tilt/ Zoom
|
Pan: 360° endless, 0.05° - 450°/s Tilt: 220°, 0.05°-450°/s 30x optical zoom and 12x digital zoom, total 360x zoom E-flip, 256 preset positions, Tour recording, Guard tour, Control queue, On-screen directional indicator, Set new pan 0°, Adjustable zoom speed |
Video Compression
|
H.264 (MPEG-4 Part 10/AVC) Baseline and Main Profiles Motion JPEG |
Video Resolution
|
HDTV 720p 1280x720 to 320x180 |
Video Framerate
|
Up to 30/25 fps (60/50 Hz) in all resolutions |
Video Streaming
|
Multiple, individually configurable streams in H.264 and Motion JPEG Controllable frame rate and bandwidth VBR/MBR H.264 |
Image settings
|
Wide Dynamic Range (WDR), manual shutter time, compression, color, brightness, sharpness, white balance, exposure control, exposure zones, backlight compensation, fine tuning of behavior at low light, rotation: 0°, 180°, text and image overlay, 32 individual 3D privacy masks, image freeze on PTZ, electronic image stabilization, automatic defog |
Security
|
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management |
Protocol Support
|
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, NTCIP |
Application Programming Interface
|
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profile S, specification at www.onvif.org |
Analytics
|
Video motion detection, Autotracking, Active Gatekeeper Support for AXIS Camera Application Platform enabling installation of AXIS Cross-line detection and third-party applications, see www.axis.com/acap |
Trigger Events
|
Analytics, Shock detection, Fan, Temperature, Manual trigger, PTZ moving, PTZ preset, Edge storage events Heater Casing open |
Event actions
|
File upload: FTP, SFTP, HTTP, HTTPS network share and email Notification: email, HTTP, HTTPS and TCP Day/night mode, Guard tour, Video recording to edge storage, Pre- and post-alarm video buffering, PTZ preset, Overlay text, Send SNMP trap |
Data streaming
|
Event data |
Built-in installation aids
|
Pixel counter |
Casing
|
IP66-, NEMA 4X- and IK10-rated metal casing (aluminum), polycarbonate (PC) clear dome, sunshield (PC/ASA) |
Memory
|
512 MB RAM, 128 MB Flash Battery backed-up real-time clock |
Connectors
|
RJ45 10BASE-T/100BASE-TX PoE, RJ45 Push-pull Connector (IP66) included |
Edge Storage
|
Support for SD/SDHC/SDXC card Support for recording to dedicated network-attached storage (NAS) For SD card and NAS recommendations see www.axis.com |
Operating Conditions
|
With 30 W: -20 °C to 50 °C (-4 °F to 122 °F) With 60 Wb : -50 °C to 50 °C (-58 °F to 122 °F) Humidity 10-100% RH (condensing) |
Storage Temperature
|
-50 °C to 60 °C (-58 °F to 140 °F) |
Weight
|
3.7 kg (8.2 lb) |
Dimension
|
Ø232 x 280 mm (Ø9.1 x 11.0 in) |
Included accessories
|
Axis High PoE 60 W Midspan 1-port, RJ45 Push-pull Connector (IP66), Sunshield Installation Guide, Windows decoder 1-user license |
Optional accessories
|
Smoked dome cover, AXIS T91A Mounting Accessories AXIS T90 Illuminators, AXIS T8310 Video Surveillance Control Board, Installation Display, Multi-user decoder license pack |
Video Management Software
|
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software |
Language
|
German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese |
