Axis Q8722-E

Continuous rotation, endless 360° pan.
IP66-rated.
HDTV image quality.
VGA thermal imaging.

Lensa

Qty:

Overview
Specifications
Contact Us

AXIS Q8722-E PTZ DOME NETWORK CAMERA

Kamera visual dan thermal AXIS Q8722-E dapat terhubung ke Ethernet switch yang ditempatkan di dalam wadah, diperlukan hanya satu kabel Ethernet untuk melihat kedua kamera. Kamera thermal dapat mencapai akurasi deteksi lebih tinggi dan juga dapat berfungsi dalam keadaan gelap gulita dan kondisi cuaca buruk. Kamera visual merupakan kamera yang dapat mengenali objek di malam hari, selain itu kamera ini mendapatkan keuntungan dari opsional PT IR Illuminator kit A untuk dapat melakukan identifikasi yang lebih baik. Kamera ini dapat beroperasi di suhu dari -30° C sampai 45° C (- 22° F sampai 113° F). AXIS Q8722-E dirancang khusus untuk diandalkan, instalasi cuaca, dengan IP66-rated bahan untuk perlindungan terhadap masuknya debu dan air dengan tekanan tinggi.

AXIS Q8722-E adalah kamera kombinasi kelas atas dari kamera visual yang terintegrasi dengan 10x optical zoom lensa dan kamera thermal yang disinkronkan dengan gerakan pan, tilt dan zoom. AXIS Q8722-E merupakan kamera dengan resolusi Kamera Visual dengan 1920x1080 HDTV 1080i, HDTV 720p 1280x720; dan kamera termal dengan 640x480 sensor, gambar dapat ditingkatkan untuk resolusi 800x600 (D1). Kamera visual dan thermal ini dapat memberikan beberapa jalur independen H.264 untuk kebutuhan kualitas yang berbeda dan keterbatasan bandwidth secara bersamaan.

FITUR AXIS Q8722-E

Sensor gambar Visual camera:1/3’’ progressive scan CMOS 2 megapixel, Thermal camera: Uncooled micro bolometer 640x480 pixels.
Lensa : f=5.1–51 mm, F1.8–2.1, Autofocus, Automatic, day/night.
Minimal iluminasi warna: 2 lux at 30 IRE, F1.8, hitam putih: 0.2 lux at 30 IRE, F1.8.
Mampu beroperasi dengan sangat baik pada suhu -30 °C to 45 °C (-22 °F to 113 °F).
Fungsi Edge Storage untuk penyimpan kartu SD/SDHC/SDXC.
Berat kamera 28.5 kg (63 lb) (IR LED excluded).

Jual kamera CCTV seperti IP Kamera, Dome Kamera, Analog Kamera dan berbagai macam jenis CCTV lainnya dari brand AXIS. JakartaCCTV distributor kamera CCTV menjual berbagai macam CCTV berkualitas dari berbagai brand ternama dengan harga murah di Jakarta. Tersedia pula jasa pemasangan CCTV yang ditangani langsung oleh teknisi - teknisi yang handal dan berpengalaman pada bidang pemasangan CCTV. Jika Anda ingin membeli Infrared camera dengan harga infrared camera murah Anda dapat menghubungi JakartaCCTV, JakartaCCTV jual ir camera di Jakarta.

Spesifikasi produk

Image Sensor	Visual camera: 1/3’’ progressive scan CMOS 2 megapixel Thermal camera: Uncooled micro bolometer 640x480 pixels
Lens	Visual camera: f=5.1–51 mm, F1.8–2.1, Autofocus, Automatic day/night Horizontal angle of view: 48.1°–5.1° M37x0.75 mounting thread for optional lens adaptor
Detection range	See tables above
Min.Illumination	Visual camera: Color: 2 lux at 30 IRE, F1.8 B/W: 0.2 lux at 30 IRE, F1.8
Sensitivity	Thermal camera: NETD < 100 mK
Shutter Time	Visual camera: 1/10000 s to 1/2 s
Pan/ Tilt/ Zoom	Pan: 360° endless, 0.1°–20°/s Tilt: 45° to -20°, 0.1°–20°/s Visual camera: 10x optical and 12x digital, total 120x Protocol: Macro Preset accuracy: 0.02°
Video Compression	H.264 (MPEG-4 Part 10/AVC) Motion JPEG
Video Resolution	Visual camera with HDTV 1080i 1920x1080, HDTV 720p 1280x720; and Thermal camera with 640x480 sensor, image can be scaled up to 800x600 (D1) resolution
Video Framerate	Visual camera: 30/25 fps in all resolutions and video compression Thermal camera: Up to 30 fps within EU, Norway, Switzerland, Canada, USA, Japan, Australia, New Zealand Up to 8.3 fps in other countries a
Video Streaming	Visual camera: Multiple, individually configurable streams in H.264 and Motion JPEG Thermal camera: At least 1 stream in H.264 and Motion JPEG: Simultaneous, individually configured streams in max. resolution at 30 fps Controllable frame rate and bandwidth, VBR/CBR H.264
Image settings	Visual camera: Compression, Brightness, Sharpness, White balance, Exposure control, Backlight compensation, Text and image overlay, Mirroring of images, Rotation Thermal camera: Compression, Brightness, Exposure control, Text and image overlay, Mirroring of images, Rotation, Multiple palettes
Security	Password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSb , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com Interface specifications available at www.axis.com
Intelligent Video	Video motion detection, Active tampering alarm AXIS Camera Application Platform enabling installation of additional applications Visual camera: Gatekeeper
Trigger Events	Intelligent video, External output
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video recording to edge storage Pre- and post-alarm video buffering External output activation
Data streaming	Event data
Casing	Aluminum casing, sunshield ABS PMMA, IP66-rated Color: RAL 9002
Memory	Visual camera: 256 MB RAM, 128 MB Flash Thermal camera: 128 MB RAM, 128 MB Flash
Power	24 V AC 50/60 Hz, 200 W provided by power supply (sold separately) 230/120 V AC 50/60 Hz with built-in day/night sensor
Edge Storage	SD/SDHC/SDXC slot supporting memory cards up to 64 GB (card not included) Support for recording to network share (network-attached storage or file server)
Operating Conditions	-30 °C to 45 °C (-22 °F to 113 °F) Humidity 10–100% RH (condensing)
Approvals	EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, C-tick AS/NZS CISPR 22 Class A, EN 60950-1, EN 60950-22, IEC/EN 60529 IP66 Power supply (sold separately): EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, C-tick AS/NZS CISPR 22 Class A, EN 60950-1, EN 60950-22, IEC/EN 60529 IP66
Weight	28.5 kg (63 lb) (IR LED excluded)
Weight	Installation Guide, Installation and Management Software CD, Windows decoder 1-user license
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software

Namamu *

Email Anda *

Pertanyaan *

AXIS Q8722-E PTZ DOME NETWORK CAMERA

FITUR AXIS Q8722-E

Sensor gambar Visual camera:1/3’’ progressive scan CMOS 2 megapixel, Thermal camera: Uncooled micro bolometer 640x480 pixels.
Lensa : f=5.1–51 mm, F1.8–2.1, Autofocus, Automatic, day/night.
Minimal iluminasi warna: 2 lux at 30 IRE, F1.8, hitam putih: 0.2 lux at 30 IRE, F1.8.
Mampu beroperasi dengan sangat baik pada suhu -30 °C to 45 °C (-22 °F to 113 °F).
Fungsi Edge Storage untuk penyimpan kartu SD/SDHC/SDXC.
Berat kamera 28.5 kg (63 lb) (IR LED excluded).

Spesifikasi produk

Image Sensor	Visual camera: 1/3’’ progressive scan CMOS 2 megapixel Thermal camera: Uncooled micro bolometer 640x480 pixels
Lens	Visual camera: f=5.1–51 mm, F1.8–2.1, Autofocus, Automatic day/night Horizontal angle of view: 48.1°–5.1° M37x0.75 mounting thread for optional lens adaptor
Detection range	See tables above
Min.Illumination	Visual camera: Color: 2 lux at 30 IRE, F1.8 B/W: 0.2 lux at 30 IRE, F1.8
Sensitivity	Thermal camera: NETD < 100 mK
Shutter Time	Visual camera: 1/10000 s to 1/2 s
Pan/ Tilt/ Zoom	Pan: 360° endless, 0.1°–20°/s Tilt: 45° to -20°, 0.1°–20°/s Visual camera: 10x optical and 12x digital, total 120x Protocol: Macro Preset accuracy: 0.02°
Video Compression	H.264 (MPEG-4 Part 10/AVC) Motion JPEG
Video Resolution	Visual camera with HDTV 1080i 1920x1080, HDTV 720p 1280x720; and Thermal camera with 640x480 sensor, image can be scaled up to 800x600 (D1) resolution
Video Framerate	Visual camera: 30/25 fps in all resolutions and video compression Thermal camera: Up to 30 fps within EU, Norway, Switzerland, Canada, USA, Japan, Australia, New Zealand Up to 8.3 fps in other countries a
Video Streaming	Visual camera: Multiple, individually configurable streams in H.264 and Motion JPEG Thermal camera: At least 1 stream in H.264 and Motion JPEG: Simultaneous, individually configured streams in max. resolution at 30 fps Controllable frame rate and bandwidth, VBR/CBR H.264
Image settings	Visual camera: Compression, Brightness, Sharpness, White balance, Exposure control, Backlight compensation, Text and image overlay, Mirroring of images, Rotation Thermal camera: Compression, Brightness, Exposure control, Text and image overlay, Mirroring of images, Rotation, Multiple palettes
Security	Password protection, IP address filtering, HTTPSb encryption, IEEE 802.1Xb network access control, Digest authentication, User access log
Protocol Support	IPv4/v6, HTTP, HTTPSb , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Application Programming Interface	Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at www.axis.com Interface specifications available at www.axis.com
Intelligent Video	Video motion detection, Active tampering alarm AXIS Camera Application Platform enabling installation of additional applications Visual camera: Gatekeeper
Trigger Events	Intelligent video, External output
Event actions	File upload: FTP, HTTP, network share and email Notification: email, HTTP and TCP Video recording to edge storage Pre- and post-alarm video buffering External output activation
Data streaming	Event data
Casing	Aluminum casing, sunshield ABS PMMA, IP66-rated Color: RAL 9002
Memory	Visual camera: 256 MB RAM, 128 MB Flash Thermal camera: 128 MB RAM, 128 MB Flash
Power	24 V AC 50/60 Hz, 200 W provided by power supply (sold separately) 230/120 V AC 50/60 Hz with built-in day/night sensor
Edge Storage	SD/SDHC/SDXC slot supporting memory cards up to 64 GB (card not included) Support for recording to network share (network-attached storage or file server)
Operating Conditions	-30 °C to 45 °C (-22 °F to 113 °F) Humidity 10–100% RH (condensing)
Approvals	EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, C-tick AS/NZS CISPR 22 Class A, EN 60950-1, EN 60950-22, IEC/EN 60529 IP66 Power supply (sold separately): EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, C-tick AS/NZS CISPR 22 Class A, EN 60950-1, EN 60950-22, IEC/EN 60529 IP66
Weight	28.5 kg (63 lb) (IR LED excluded)
Weight	Installation Guide, Installation and Management Software CD, Windows decoder 1-user license
Video Management Software	AXIS Camera Station and video management software from Axis’ Application Development Partners (not included). For more information, see www.axis.com/products/video/software
