Resolution 1 MP , 720P@ 25fps, D1@ 2fps
General
Image Sensor 1/ 4" Omnivision 1 Megapixel CMOS Sensor
Number of Pixels 1080( H) x976( V) / 976( H) x582( V)
Min. Illumination 1.0 Lux
S/ N Ratio More than 50dB
Focus Mode manual
Day/ Night IR cut filter with auto switch
Weatherproof IP66
Network 1 Rj45Ethernet interface.10/ 100M adaptation
Delay Within The LAN0.3S
Lens Board lens 3.6mm / F2.0
Frame rate 25 FPS( adjustable)
Video Compression H.264/ JPEG
Protocol TCP/ UDP/ RTSP/ FTP/ PPPOE/ DHCP/ DDNS/ NTP/ UPnP/ SMTP
Onvif Support Onvif 2.0
User Permission Multi-user Classification Mangement
Lens Board Lens 3.6mm/ F2.0
IR Status IR LED : 5x24PCS IR Range : 20M
Power Source ( ± 10% ) DC12V/ 1000MA
Current / Power consumption ( ± 10% ) 3.0 W
Dimensions ( mm) 148( W) ( ˜ ) x 65( H) x63( D) mm
Humidity 0% -90% RH, Without Condensation
Operating Temperature -20~ 50 C
Weight ( g) 500ÿ ÿ
