Spesifikasi :
Camera
Image Sensor
1/3-type 760H Super HAD CCD II
Image Sensor (Number of Effective Pixels)
Approx. 0.44 Megapixels
Signal System
PAL
Minimum Illumination (50 IRE)
Color: 0.30 lx (F1.8 AGC ON) B/W: 0.20 lx (F1.8 AGC ON)
Minimum Illumination (30 IRE)
Color: 0.18 lx (F1.8 AGC ON) B/W: 0.07 lx (F1.8 AGC ON)
S/N Ratio
More than 55 dB (AGC Off)
Gain
Auto (on/off)
Shutter Speed
Auto
Sync System
Internal Only
White Balance
ATW (2000K to 10000K)
Lens
Mono-focal type
Powered Zoom
No
Horizontal Viewing Angle
46°
Swivel Range
340°
Focal Length
f = 6.0 mm
F-Number
F1.8
Minimum Object Distance
400 mm
Horizontal Resolution
540 TVL
Pan/Tilt Angle
340°/±75°
Infrafed Illuminators
Camera Features
Day/Night
Yes (Electrical D/N)
Image Enhancement
Yes (ATR-Lite, on/off), Yes (iBLC, on/off)
Noise Reduction
Yes (2DNR, on/off)
Interface
Analog Monitor Output
VBS: 1.0Vp-p
General
Power Requirements
DC12V ±10%
Power Consumption
0.9 W max.
Operating Temperature
-10°C to +50°C 14°F to 122°F
Storage Temperature
-40°C to +60°C -40°F to +140°F
Operating Humidity
20% to 80%
Storage Humidity
20% to 95%
Vandal Resistant
Dimensions *1
φ85.2 x 63.5 mm φ3 3/8 x 2 1/2 inches
Mass
140 g 4.9 oz
Safety Regulations
EN55022(Class A)+EN50130-4 EN55022(Class A)+EN55024 AS/NZS CISPR22 Class A IEC60065 GOST-R IEC60065 compliance
Ingress Protection
Supplied Accessories
Operating instructions (1)
