Spesifikasi :
Camera
Image Sensor
1/3-type 960H EXview HAD CCD II
Image Sensor (Number of Effective Pixels)
Approx. 0.57 Megapixels
Signal System
PAL
Minimum Illumination (50 IRE)
B/W: 0 lx (F1.8)
S/N Ratio
More than 55 dB
Gain
Auto
Shutter Speed
Sync System
Internal Only
White Balance
ATW (2000K to 10000K)
Lens
Mono-focal type
Powered Zoom
No
Powered Focus
Horizontal Viewing Angle
46.5°
Vertical Viewing Angle
34.5°
Swivel Range
350°
Focal Length
f = 6 mm
F-Number
F2.0
Minimum Object Distance
800 mm
Horizontal Resolution
650 TVL
Pan/Tilt Angle
355°/±66°
Infrafed Illuminators
10 pcs
Infrared Irradiation Distance
10 m at 50 IRE
Camera Features
Day/Night
Yes (True D/N)
Image Enhancement
Yes (ATR-Lite)
Noise Reduction
Yes (2DNR)
Interface
Analog Monitor Output
VBS: 1.0Vp-p
General
Power Requirements
DC 12 V ±10%
Power Consumption
2.9 W max.
Operating Temperature
-10°C to +50°C 14°F to 122°F
Storage Temperature
-40°C to +60°C -40°F to +140°F
Operating Humidity
20% to 80%
Storage Humidity
20% to 95%
Vandal Resistant
Dimensions *1
φ121.6 mm x 86.5 mm φ4 7/8 inches x 3 1/2 inches
Mass
260 g 9.2 oz
Safety Regulations
EN55022(Class A)+EN50130-4 EN55022(Class A)+EN55024 AS/NZS CISPR22 Class A IEC60065 GOST-R IEC60065 compliance
Ingress Protection
Supplied Accessories
Operating instructions (1) Template (1)
