SAMSUNG SNV-8081RP

tidak termasuk pengiriman

• Max. 5megapixel (2592 x 1944) resolution
• 30fps@5M, 60fps@2M
• 0.15Lux@F1.3 (Color), 0Lux (B/W : IR LED on)
• 3.93 ~ 9.4mm (2.4x) motorized varifocal lens
• H.265, H.264, MJPEG support
• Day & Night (ICR), WDR (120dB), Simple focus, P-Iris
• Tampering, Audio detection
• micro SD/SDHC/SDXC memory slot, NAS, Local PC support
• Hallway view (Rotate 90 ̊ / 270 ̊)
• LDC (Lens Distortion Correction)
• IP66, IK10, Bi-directional audio support

Qty:

Overview
Contact Us

Jual IP Camera murah, SAMSUNG HANWHA TECHWIN SNV-8081RP CCTV, yang bisa anda beli sekarang dari JakartaCCTV dengan harga kompetitif dan terjangkau. IP Kamera dome HANWHA ini dilengkapi dengan lensa motorized vari-focal 3.93-9.4 mm yang terlindungi dalam casing anti air IP66 dan anti pencurian / anti pengrusakan IK10 dan mampu menyesuaikan bukaan lensa kamera secara otomatis ketika sedang beroperasi, sehingga menghasilkan fleksibilitas pada area pandang kamera sekuriti, serta menangkap gambar & video dengan resolusi hingga 5MP.

Kamera ini cocok untuk penempatan di area outdoor karena diperlengkapi dengan Simple Focus, Filter IR Cut Day/Night yang dapat menampilkan image berwarna pada siang hari dan beralih ke image monochrome pada saat suasana berangsur gelap, teknologi True WDR yang digunakan untuk menangkap gambar yang jelas pada kondisi dimana objek dikelilingi oleh cahaya belakang yang kuat/terang, sambil menjaga latar belakangnya agar dapat terlihat jelas, tampering detection yang dapat mendeteksi ketika kamera diganggu, audio detection yang dapat mendeteksi suara yang lebih keras dari tingkat tertentu yang dispesifikasikan oleh pengguna serta berbagai fitur cerdik lainnya.

Di samping itu kamera ini juga mendukung hallway view mode yang dapat mengganti aspek rasio untuk pemantauan lebih optimal pada area vertikal seperti koridor, terowongan dsb., penyimpanan on board melalui Micro SD Card Slot, serta komunikasi audio dua arah yang memungkinkan penggunanya untuk mendengar dan berbicara dengan subjek yang sedang diawasi.

FITUR & FUNGSI SAMSUNG SNV-8081RP

Max. 5megapixel (2592 x 1944) resolution
30fps@5M, 60fps@2M
0.15Lux@F1.3 (Color), 0Lux (B/W : IR LED on)
3.93 ~ 9.4mm (2.4x) motorized varifocal lens
H.265, H.264, MJPEG support
Day & Night (ICR), WDR (120dB), Simple focus, P-Iris
Tampering, Audio detection
micro SD/SDHC/SDXC memory slot, NAS, Local PC support
Hallway view (Rotate 90 ̊ / 270 ̊)
LDC (Lens Distortion Correction)
IP66, IK10, Bi-directional audio support

Hubungi kami sekarang untuk mendapatkan penawaran terbaik dengan harga distributor yang murah untuk IP Cam HANWHA SNV-8081RP ini yang disertai dengan garansi resmi 2 tahun dari distributor HANWHA TECHWIN di Indonesia. Kami, JakartaCCTV akan dengan senang hati membimbing dan membantu anda memilih IP Kamera SAMSUNG atau paket CCTV lainnya yang paling cocok untuk kebutuhan anda serta memberikan penawaran untuk jasa pasang CCTV & proses settingnya.

VIDEO
Imaging Device	1/1.8" 6M CMOS
Total Pixels / Effective Pixels	3,096(H) x 2,094(V) / 2,616(H) x 1,976(V)
Scanning System	Progressive
Min. Illumination	Color : 0.3Lux (1/30sec, F1.3, 50IRE), 0.005Lux (2sec, F1.3, 50IRE) 0.15Lux (1/30sec, F1.3, 30IRE), 0.003Lux (2sec, F1.3, 30IRE) B/W : 0Lux (IR LED on)
S / N Ratio	50dB
Video output	CVBS : 1.0 Vpp / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation DIP connector type
LENS
Focal Length (Zoom Ratio)	3.93 ~ 9.4mm (2.4x) motorized varifocal
Max. Aperture Ratio	F1.3
Angular Field of View	H : 93.4°(Wide) ~ 39.2°(Tele) / V : 68.1°(Wide) ~ 29.3°(Tele)
Min. Object Distance	0.5m (1.64ft)
Focus Control	Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus)
Lens Type / Mount Type	DC auto iris, support P-Iris mode / Board-in type
PAN / TILT / ROTATE
Pan / Tilt / Rotate Range	0° ~ 354° / 0° ~ 67° / 0° ~ 355°
OPERATIONAL
Viewable Length	30m (98.43ft), Smart IR
Camera Title	Off / On (Displayed up to 15 characters)
Day & Night	Auto (ICR) / Color / B/W / External / Schedule
Backlight Compensation	Off / BLC / WDR
Wide Dynamic Range	120dB
Contrast Enhancement	SSDR (Off / On)
Digital Noise Reduction	SSNR (2D+3D noise filter) (Off / On)
Motion Detection	Off / On (4ea, Rectangle)
Privacy Masking	Off / On (6ea, Rectangle) - Color : Black / Blue / Red / Grey / White / Green
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor (Include mercury & sodium)
LDC (Lens Distortion Correction)	Off / On (Level auto control)
Electronic Shutter Speed	Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
Flip / Mirror	Off / On, Hallway : 90° /270°
Intelligent Video Analytics	Tampering, Audio detection - with metadata
Alarm I/O	Input 1ea / Output 1ea
Alarm Triggers	Alarm input, Motion detection, Tampering, Audio detection, Network disconnect
Alarm Events	File upload via FTP and E-mail, Notification via E-mail Local storage (SD/SDHC/SDXC) or NAS recording at event triggers, External output
Pixel Counter	Support
NETWORK
Ethernet	RJ-45 (10/100BASE-T)
Video Compression Format	H.265 : Main, H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG
Resolution	5M mode : 2592 x 1944, 2592 x 1464, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240 2M mode : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240
Max. Framerate	5M mode - H.265 / H.264 : 30fps in all resolutions MJPEG : 2592 x 1944 ~ 2592 x 1464 : 2fps, 1920 x 1080 ~ 1600 x 1200 : 4fps 1280 x 1024 ~ 1024 x 768 : 5fps, 800 x 600 ~ 320 x 240 : 15fps 2M mode - H.265 / H.264 : 60fps in all resolutions MJPEG : 1920 x 1080 : 4fps, 1280 x 1024 ~ 1024 x 768 : 5fps, 800 x 600 ~ 320 x 240 : 15fps
Smart Codec	Manual mode (Area-based : 4ea)
Video Quality Adjustment	H.265 / H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method	H.265 / H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability	Multiple streaming (Up to 3 profiles) - Total 3 stream at the same time (Including recording stream)
Audio In	Selectable (Mic in / Line in) Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
Audio out	Line out (3.5mm stereo mini jack), Max output level : 1Vrms
Audio Compression Format	G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication	Bi-directional audio (2-way)
IP	IPv4, IPv6
Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication (EAP-TLS, EAP-LEAP)
Streaming Method	Unicast / Multicast
Max. User Access	10 users at unicast mode
Edge Storage	micro SD/SDHC/SDXC (128GB) - Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded, Camera can detect automatically when the memory is connected, Memory status display (Normal / Error / Active / Formatting / Lock), NAS (Network Attached Storage), Local PC for instant recording
Application Programming Interface	ONVIF profile S, SUNAPI (HTTP API), SVNP, Wisenet Open Platform
Webpage Language	English, French, German, Spanish, Italian, Chinese, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Web Viewer	Supported OS : Windows XP / VISTA / 7 / 8 / 8.1 or higher, MAC OS X 10.7 ~ 10.10 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 35), Google Chrome (Ver. 15 ~ 40), Apple Safari (Ver. 8.0.2 (Mac OS X 10.10), 7.0.6 (Mac OS X 10.9), 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only
Central Management Software	SmartViewer, SSM
ENVIRONMENTAL
operating Temperature / Humidity	-40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH * Start up should be done at above -35°C (-31°F)
Storage Temperature / Humidity	-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection / Vandal Resistance	IP66 / IK10
ELECTRICAL
Input Voltage / Current	24V AC ±10%, 12V DC ±10%, PoE (IEEE802.3af, Class3)
Power Consumption	Max. 12W/13.5W (24V AC, Heater off / on), Max. 10W/11.5W (12V DC, Heater off / on), Max. 11.5W/12.95W (PoE, Heater off / on)
MECHANICAL
Color / Material	Ivory / Aluminium
Dimensions (WxHxD)	Ø160.0 x 118.5mm (Ø6.3" x 4.67")
Weight	955g (2.11 lb)
