Imaging Device
|
1/1.8" 6M CMOS (IMX178) |
Total Pixels
|
6megapixel |
Scanning System
|
Progressive scan |
Min.Illumination
|
Color : 0.5Lux (F2.5, 50IRE), 0.2Lux (F2.5, 30IRE) B/W : 0.05Lux (F2.5, 50IRE), 0.02Lux (F2.5, 30IRE) |
Focal Lenght (Zoom Ratio)
|
1.14mm fixed |
Max. Aperture Ratio
|
F2.5 |
Angular Field of View
|
H : 187° / V : 187° / D : 187° |
Min. Object Distance
|
0.3m |
Focus Control
|
Infinity / Manual |
Lens Type
|
Fixed |
Mount Type
|
Board type (M12) |
Camera Title
|
Off / On (Displayed 15 characters) |
Day/Night
|
True Day and Night |
Backlight Compensation
|
Off / BLC |
Wide Dynamic Range
|
60dB (SSDR) |
Contrast Enhancement
|
SSDR (Off / On) |
Noise Reduction
|
SSNR III (2D+3D noise filter) (Off / On) |
Motion Detection
|
Off / On (4ea, Rectanglular zones) |
Privasi masking
|
Off / On (32ea, Rectanglular zones) |
Gain Control
|
Low / Middle / High / Off |
White Balance
|
ATW / Indoor / Outdoor / AWC / Manual / Mercury |
Electronic Shutter
|
2 ~ 1/12,000sec |
Digital Zoom
|
16x, Digital PTZ (Preset, Group) |
Flip / Mirror
|
Off / On |
Intelligent Video Analytics
|
Tampering, Audio detection |
Alarm I/O
|
Input 1ea / Output 1ea |
Alarm Triggers
|
Motion detection, Tampering, Audio detection, Alarm input, Network disconnection |
Alarm Events
|
File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP Local storage (SD/SDHC/SDXC) recording at Network disconnected & Event (Alarm triggers), External output |
Viewing Composition
|
Camera : 360 source view, Single panorama, Double panorama, Quad view, Single rectangle CMS : 360 source view, Single panorama, Double panorama, Quad view, Single rectangle, 360 source view + 3 rectangle, Single panorama + 2 rectangle |
Ethernet
|
RJ-45 (10/100BASE-T) |
Video Compression
|
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution Original View
|
2560 x 2048, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 480, 640 x 480, 320 x 240 |
Resolution Dewarped View
|
1. Single rectangle : 800 x 600, 640 x 480, 320 x 240 2. Quad view : 1600 x 1200, 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 320 x 240 3. Double panorama : 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 320 x 240 4. Single panaroma : 2048 x 768, 1600 x 600, 1280 x 480, 1024 x 384, 800 x 300, 640 x 240, 320 x 120 |
Max. Framerate MJPEG
|
Source view - 2560 x 2048 : 10fps 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : 15fps 800 x 600, 720 x 480, 640 x 480, 320 x 240 : 20fps Single panorama view - 2048 x 768, 1600 x 1200, 1280 x 480, 1024 x 384 : 15fps 800 x 300, 640 x 240, 320 x 120 : 20fps Double panorama view - 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768 : 15fps 800 x 600, 640 x 480, 320 x 240 : 20fps Quad view - 1600 x 1200, 1280 x 960, 1024 x 768 : 15fps 800 x 600, 640 x 480, 320 x 240 : 20fps Single rectangle view - 800 x 600, 640 x 480, 320 x 240 : 20fps |
Max. Framerate H.264
|
Max. 20fps at all resolution |
Video Quality Adjustment
|
H.264 : Compression level, Target bitrate level control MJPEG : Quality level control |
Bitrate Control
|
H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability
|
Multiple streaming (Up to 5 profiles) |
Audio Input
|
Selectable (Mic in / Line in : SNF-8010/8010VM), Built-in Mic : SNF-8010 Supply voltage : 2.5V DC (4mA), Input impedance : approx 2K ohm |
Audio Output
|
Line out (3.5mm mono jack), Max output level : 1 Vrms |
Audio Compression
|
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Audio Communication
|
Bi-directional audio |
IP
|
IPv4, IPv6 |
Protocol Support
|
TTCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour |
Security
|
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
Streaming Method
|
Unicast / Multicast |
Max. User Access
|
10 users at unicast mode |
Edge Storage
|
micro SD/SDHC/SDXC (64GB) - Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded, NAS (Network Attached Storage) |
Application Programming Interface
|
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
Webpage Language
|
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
Web Viewer
|
Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
Central Management Software
|
SmartViewer, SSM |
Operating Temperature
|
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Storage Temperature
|
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
Ingress Protection
|
IP66 |
Vandal Resistance
|
IK10 |
Standard Certification
|
UL, CE, FCC, RoHS, Gost, KC |
Input Voltage / Current
|
12V DC, PoE (IEEE802.3af class 3) |
Power Consumption (±10%)
|
Max. 8.7W (12V DC), Max. 10.3W (PoE) |
Color / Material
|
Ivory / Aluminium |
Dimensions (mm)
|
Ø145.9 x 49.6mm (Ø5.74" x 1.95") |
Weight
|
780g (1.72 lb) |
Effective Pixels
|
5.2M (2,560 x 2,048) |
