SAMSUNG SNF-8010VMP

tidak termasuk pengiriman

• Max. 5M (2560 x 2048) resolution
• Various viewing composition, 6 dewarping view mode
• On board dewarping, Digital PTZ / Bi-directional audio
• WDR (60dB), MD, AD
• M12 connector
• IP66, NEMA4X, IK10, EN50155, EN61373
• micro SD/SDHC/SDXC memory slot, PoE

Qty:

Overview
Contact Us

Jual IP Camera murah, SAMSUNG HANWHA TECHWIN SNF-8010VMP CCTV, yang bisa anda beli sekarang dari JakartaCCTV dengan harga kompetitif dan terjangkau. IP Kamera Fisheye HANWHA ini menawarkan tinjauan 360^o ketika menangkap gambar & video dengan resolusi hingga 5MP. Tinjauan gambar dan video ini lalu bisa di dewarp (sebuah fitur yang “membongkar” tinjauan 360^o menjadi berbagai variasi komposisi pemantauan) secara real time atau non-real time ke dalam 6 mode pemantauan yang berbeda. Fitur cerdik ini mengijinkan pengguna untuk mengcover area yang luas dengan sebuah perangkat tunggal, dan di saat yang sama memiliki pandangan yang “normal” dari gambar yang seharusnya terdistorsi atau terbalik.

Kamera ini juga bisa difungsikan secara digital sebagai kamera Pan Tilt Zoom karena dapat merotasi tinjauan image/video secara horizontal & vertikal lalu menzoom tinjauan image/video terotasi tsb. Menggabungkan fungsi ini dengan fungsi fungsi lain pada kamera seperti tampering detection yang dapat mendeteksi ketika kamera diganggu, dan audio detection yang dapat mendeteksi suara yang lebih keras dari tingkat tertentu yang dispesifikasikan oleh pengguna akan membuat kamera ini menjadi sebuah alat yang serba guna untuk sistem pemantauan indoor anda.

Selain itu, di dalam casingnya yang memiliki rating weatherproof IP66, anti debu NEMA4X & anti maling IK10, kamera ini juga mendukung PoE (Power Over Ethernet), penyimpanan on board melalui Micro SD Slot, serta komunikasi audio dua arah yang memungkinkan penggunanya untuk mendengar dan berbicara dengan subjek yang sedang diawasi.

FITUR & FUNGSI SAMSUNG SNF-8010VMP

Max. 5M (2560 x 2048) resolution
Various viewing composition, 6 dewarping view mode
On board dewarping, Digital PTZ / Bi-directional audio
WDR (60dB), MD, AD
M12 connector
IP66, NEMA4X, IK10, EN50155, EN61373
micro SD/SDHC/SDXC memory slot, PoE

Hubungi kami sekarang untuk mendapatkan penawaran terbaik dengan harga distributor yang murah untuk IP Cam HANWHA SNF-8010VMP ini yang disertai dengan garansi resmi 2 tahun dari distributor HANWHA TECHWIN di Indonesia. Kami, JakartaCCTV akan dengan senang hati membimbing dan membantu anda memilih IP Kamera SAMSUNG atau paket CCTV lainnya yang paling cocok untuk kebutuhan anda serta memberikan penawaran untuk jasa pasang CCTV & proses settingnya.

VIDEO
Imaging Device	1/1.8" 6M CMOS (IMX178)
Total Pixels / Effective Pixels	6megapixel / 5.2M (2,560 x 2,048)
Scanning System	Progressive
Min. Illumination	Color : 0.5Lux (F2.5, 50IRE), 0.2Lux (F2.5, 30IRE) B/W : 0.05Lux (F2.5, 50IRE), 0.02Lux (F2.5, 30IRE)
LENS
Focal length / Max. Aperture Ratio	1.14mm fixed / F2.5
Angular Field of View	H : 187° / V : 187° / D : 187°
Min. Object Distance / Focus Control	0.3m (0.98ft) ~ Infinity / Manual
Lens Type / Mount Type	Fixed lens / Board type (M12)
OPERATIONAL
Camera Title	Off / On (Displayed up to 15 characters)
Day & Night / Backlight Compensation	True D&N / BLC
Wide Dynamic Range	60dB (SSDR)
Contrast Enhancement	SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction	SSNR (2D+3D noise filter) (Off / On)
Motion Detection	Off / On (4ea rectangle zones)
Privacy Masking	Off / On (32 zones with rectangle)
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor (Include mecury)
Electronic Shutter Speed	2 ~ 1/12,000sec
Flip / Mirror	Off / On
Intelligent Video Analytics	Tampering, Audio detection
Alarm I/O	Input 1ea / Output 1ea
Alarm Triggers	Motion detection, Tampering, Audio detection, Alarm input, Network disconnection
Alarm Events	File upload via FTP and E-Mail, Notification via E-Mail, TCP and HTTP Local storage (SD/SDHC/SDXC) recording at network disconnected & event (Alarm triggers), External output
Viewing Composition	Camera : 360 source view, Single panorama, Double panorama, Quad view, Single rectangle CMS : 360 source view, Single panorama, Double panorama, Quad view, Single rectangle, 360 source view + 3 rectangle, Single panorama + 2 rectangle
NETWORK
Ethernet	RJ-45 (10/100BASE-T) : Female type, M12 connector type
Video Compression Format	H.264 (MPEG-4 part 10/AVC), MJPEG
Resolution	Original View 2560 x 2048, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 480, 640 x 480, 320 x 240 Dewarped View 1. Single rectangle : 800 x 600, 640 x 480, 320 x 240 2. Quad view : 1600 x 1200, 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 320 x 240 3. Double panorama : 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 320 x 240 4. Single panaroma : 2048 x 768, 1600 x 600, 1280 x 480, 1024 x 384, 800 x 300, 640 x 240, 320 x 120
Max. Framerate	MJPEG Source view - 2560 x 2048 : 10fps 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : 15fps 800 x 600, 720 x 480, 640 x 480, 320 x 240 : 20fps Single panorama view - 2048 x 768, 1600 x 1200, 1280 x 480, 1024 x 384 : 15fps 800 x 300, 640 x 240, 320 x 120 : 20fps Double panorama view - 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768 : 15fps 800 x 600, 640 x 480, 320 x 240 : 20fps Quad view - 1600 x 1200, 1280 x 960, 1024 x 768 : 15fps 800 x 600, 640 x 480, 320 x 240 : 20fps Single rectangle view - 800 x 600, 640 x 480, 320 x 240 : 20fps H.264 Max. 20fps at all resolution
Video Quality Adjustment	H.264 : Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method	H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability	Multiple streaming (Up to 5 profiles)
Audio In	Selectable Line in Supply voltage : 2.5V DC (4mA), Input impedance : approx 2K ohm
Audio Out	Line out (3.5mm stereo mini jack), Max output level : 1Vrms
Audio Compression Format	G.711 u-law / G.726 selectable G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication / IP	Bi-directional / IPv4, IPv6
Protocol	TTCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
Streaming Method	Unicast / Multicast
Max. User Access	10 users at unicast mode
Edge Storage	micro SD/SDHC/SDXC (64GB) - Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded, NAS (Network Attached Storage)
Application Programming Interface	ONVIF profile S, SUNAPI (HTTP API) v2.0, SVNP 1.2
Webpage Language	English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian
Web Viewer	Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 Only), 5.1.7) *Mac OS X only
Central Management Software	SmartViewer, SSM
ENVIRONMENTAL
operating Temperature / Humidity	-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH *Start up should be done at above -25°C (-13°F)
Storage Temperature / Humidity	-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection / Vandal Resistance	IP66 / NEMA4X / IK10
Standard Certification	UL, CE, FCC, RoHS, Gost, KC, EN-61373, EN-50155
ELECTRICAL
Input Voltage / Current	12V DC ±10%, PoE (IEEE802.3af class3)
Power Consumption	Max. 8.7W (12V DC), Max. 10.3W (PoE)
MECHANICAL
Color / Material	Ivory / Aluminum (Clear dome cover)
Dimensions (WxH) / Weight	Ø145.9 x 62.4mm (Ø5.74" x 2.46") / 800g (1.76 lb)
