VIDEO |
|
Imaging Device |
1/2.8" 3.2M CMOS |
Total Pixels |
2,065(H) x 1,565(V) |
Effective Pixels |
2,065(H) x 1,553(V) |
Scanning System |
Progressive |
Min. Illumination |
Color : 0.1Lux (F1.2, 50IRE), 0.06Lux (F1.2, 30IRE), 0.0017Lux (2sec, F1.2, 30IRE) B/W : 0.01Lux (F1.2, 50IRE), 0.006Lux (F1.2, 30IRE), 0.00017Lux (2sec, F1.2, 50IRE) |
S / N Ratio |
50dB |
Video Output |
CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation DIP connector type |
LENS |
|
Focal Length (Zoom Ratio) |
3 ~ 8.5mm (2.8x) motorized varifocal |
Max. Aperture Ratio |
F1.2 |
Angular Field of View |
H : 100.12°(Wide) ~ 35.38°(Tele) / V : 73.76°(Wide) ~ 26.58°(Tele) |
Min. Object Distance |
0.5m (1.64ft) |
Focus Control |
Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
Lens Type / Mount Type |
DC auto iris, P-Iris / Board-in type |
Pan / Tilt / Rotate |
|
Pan / Tilt / Rotate Range |
0° ~ 354° / 0° ~ 67° / 0° ~ 355° |
OPERATIONAL |
|
IR LED |
12ea |
Viewable Length |
25m (82.02ft) |
Camera Title |
Off / On (Displayed up to 45 characters) |
Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
Backlight Compensation |
Off / BLC / WDR |
Wide Dynamic Range |
120dB |
Contrast Enhancement |
SSDR (Samsung Super Dynamic Range) (Off / On) |
Digital Noise Reduction |
SSNRIII (2D+3D noise filter) (Off / On) |
Digital Image Stabilization |
Off / On |
Defog |
Off / Auto / Manual |
Motion Detection |
Off / On (4 zones with 4-sided polygon) |
Privacy Masking |
Off / On (32 zones with 4-sided polygon) |
Gain Control |
Off / Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec) |
Flip / Mirror |
Off / On |
Intelligent Video Analytics |
Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection with metadata |
Alarm I/O |
Input 1ea / Output 1ea |
Alarm Triggers |
Motion detection, Tampering, Audio detection, Face detection, Network disconnection, Video analytics, Alarm input |
Alarm Events |
File upload via FTP and E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at Event, External output |
NETWORK |
|
Ethernet |
RJ-45 (10/100BASE-T ) |
Video Compression Format |
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution |
2048 x 1536, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Max. Framerate |
H.264 : Max. 30fps@2048 x 1536, 1600 x 1200, Max 60fps@the other resolutions MJPEG : Max. 10fps@2048 x 1536 Max. 15fps@1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Smart Codec |
Manual mode (Area-based : 5ea), Face detection mode |
Video Quality Adjustment |
H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control |
Bitrate Control Method |
H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability |
Multiple streaming (Up to 10 profiles) |
Audio In |
Selectable (Mic in / Line in / Built-in mic), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
Audio Out |
Line out (3.5mm mono jack), Max output level : 1 Vrms |
Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Audio Communication |
Bi-directional audio |
IP |
IPv4, IPv6 |
Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security |
HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication |
Streaming Method |
Unicast / Multicast |
Max. User Access |
15 users at unicast mode |
Edge Storage |
micro SD/SDHC/SDXC-Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded NAS (Network Attached Storage) |
Application Programming Interface |
ONVIF profile S, HTTP API (SUNAPI) 2.0, SVNP 1.2 |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish |
Web Viewer |
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 Supported Browser : Microsoft Internet Explorer (Ver. 11 ~ 8) Mozilla Firefox (Ver. 19 ~9) * Windows only Google Chrome (Ver. 25 ~ 15) * Windows only Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only |
Central Management Software |
SmartViewer, SSM |
ENVIRONMENTAL |
|
operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
Storage Temperature / Humidity |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
ELECTRICAL |
|
Input Voltage / Current |
12V DC, PoE (IEEE802.3af class 3) |
Power Consumption |
Max. 10.0W (12V DC), Max. 11.0W (PoE) |
MECHANICAL |
|
Color / Material |
Ivory / Aluminum |
Dimensions (WxHxD) |
Ø132.1 x 107.6mm (Ø5.2" x 4.24") |
Weight |
575g (1.27 lb) |
