Samsung SND-6011R

Video

• Ethernet : RJ-45 (10/100BASE-T)

• Video Compression Format : H.264 (MPEG-4 part 10/AVC), MJPEG

• Resolution : 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 320 x 240, 320 x 180

• Max Framerate : H.264: Max. 60fps at all resolutions MJPEG: 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768: Max 15fps, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180: Max.30fps

• Video Quality Adjustment : H.264: Compression level, Target bitrate level control, MJPEG: Quality level control

• Bitrate Control Method : H.264: CBR or VBR, MJPEG: VBR

• Steaming Capacity : Multiple streaming (Up to 10 profiles)

• IP : 1

• Protocol : TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, ONVIF Profile S

• Security : HTTPS(SSL) login authentication, Digest login authentication, IP address filtering, User access log, 802.1x authentication

• Streaming Method : Unicast /Multicast

• Max User Access : 15 users at unicast mode

• Memory Slot : Micro SD/SDHC/SDXC (Motion images recorded in the SDXC/SDHC/SD memory card can be downloaded)

• ONVIF Conformance : Yes

• Webpage Language : English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norwegian, Finnish, Norwegian

• Web Viewer : Supported OS: Windows XP / VISTA / 7, MAC OS X 10.7 or higher, Supported Browser : Internet Explorer 7.0 or Higher, Firefox 9.0 or Higher, Chrome 15.0 or Higher, Safari 5.1 or Higher

• Central Management Software : SmartViewer 4.0

Mechanical

• Colour-Material : Ivory / Plastic

• Dimensions WxHxD : Ø120.0 x 101.8mm (Ø4.72" x 4.01")

• Weight : 380g (0.84 lb)

Operational

• Camer Title : Off / On (Displayed up to 45 characters)

• Day And Night : Auto (ICR) / Color / B/W

• Backlight Compensation : Off / BLC

• Wide Dynamic Range : 120dB

• Contrast Enhancement : SSDR (Samsung Super Dynamic Range) (Off / On)

• Digital Noise Reduction : SSNRIII (2D+3D noise filter) (Off / On)

• Digital ImageS tabilization : Off / On

• Motion Detection : Off / On (4ea, 4 points polygonal zones)

• Privacy Masking : Off / On (32 zones with 4 points of polygonal)

• Gain Control : Off / Low / Middle / High

• White Balance : ATW / AWC / Manual / Indoor / Outdoor

• Electronic Shutter Speed : Auto / A.FLK / Manual (1/30 ~ 12,000sec)

• Flip-Mirror : Off /On

• VPS : Yes

• IVA : Yes

• IVA detail : Tampering, Virtual line, Enter/Exit, Appear / Disappear, Face detection, with metadata

• Alarm I-O : Input 1 ea

Chipset

• Chipset : WN3

Video

• Imaging Devise : 1/2.8" PS Exmor 2.38M CMOS

• Total Pixels : 1,952(H) x 1,236(V)

• Effective Pixels : 1,944(H) x 1,224(V)

• Scanning System : Progressive

• MinIllumination TBD : Color: 0.3Lux (F2.0, 50IRE), 0.03Lux (2sec, 50IRE), B/W: 0Lux (IR LED on)

• S-N Ratio : 50dB

• Video Output : CVBS: 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P)

Lens

• Focal Length : 3.8mm

• Max Aperture Ratio : F2.0

• Angular Field of View : H: 84.5° / V: 45.8° / D: 98.8°

• Min Object Distance : 0.5m (1.64ft)

• Focus Control : Manual

• Lens Type : Fixed

• Mount Type : Board-in Type

Electrical

• Input Voltage -Current : PoE (IEEE802.3af)

• Power Consumption : Max. 8.0W

Pan-Tilt-Rotate

• Pan Range : 0° ~ 354°

• Tilt Range : 0° ~ 67°

• Rotate Range : 0° ~ 355°

Environmental

• Operating Temperature-Humidity : -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
